4.1 mm Round Type LED , Viewing Angle - for Transparent and Water-36°
- for Diffused-85°
Package Dimension
52H Series
Directivity Radiation
All Dimensions are in mm (inch)
Electrical Characterstics
Electro - Optical
Part No.
Chip Material
Emitted
Colour
Lens Colour
Wave
Length
Characterstics
(I
f
= 20mA)
V
f
(v)
Typ.
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
2.6
2.6
2.6
2.6
2.6
2.6
Max
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
3.8
3.8
3.8
3.8
3.8
3.8
I
v
(mcd)
2
10
100
400
25
100
25
100
25
100
300
1200
6000
6000
3000
800
λP
(nm)
52H70D-4001
52H70T-4001
52H71D-4001
52H71T-4001
52H41D-4001
52H41T-4001
52H51D-4001
52H51T-4001
52H61D-4001
52H61T-4001
52H11D-4001
52H11C-4001
52H22C-4001
52H32C-4001
52H82C-4001
52H82W-4001
GaP/GaP
GaP/GaP
GaAsP/GaP
GaAsP/GaP
GaP/GaP
GaP/GaP
GaAsP/GaP
GaAsP/GaP
GaAsP/GaP
GaAsP/GaP
GaN
GaN
GaN
GaN
GaN
GaN
Hi-Red
Hi-Red
Hi-Eff Red
Hi-Eff Red
Yellow Green
Yellow Green
Yellow
Yellow
Orange
Orange
Blue
Blue
Blue Green
Green
White
White
Red Diffused
Red Transparent
Red Diffused
Red Transparent
Green Diffused
Green Transparent
Yellow Diffused
Yellow Transparent
Orange Diffused
Orange Transparent
Blue Diffused
Water
Water
Water
Water
Water Diffused
700
700
640
640
570
570
585
585
605
605
470
470
505
525
52H_LEDRev100506D
Continental Device India Limited
Page 1 of
2
Other Parameters applicable for all LEDs
Electrical Parameter
Reverse
Voltage
V
r
(v)
Green (GaP)
Red (GaP)
Orange
(GaAsP/GaP)
Yellow
(GaAsP/GaP)
Ultra Yellow
(AlGaInP)
Ultra Orange
(AlGaInP)
Ultra Red
(AlGaInP)
Ultra Yellow
Green
Blue
(GaN/SiC)
6
6
6
6
6
6
6
6
6
Forward
Current
I
f
(mA)
25
25
25
25
30
30
30
30
30
Forward Current
Peak
I
fp
*
(mA)
100
100
100
100
100
100
100
100
100
(at T
a
= 25ºC)
Power Pd
(mW)
80
80
80
80
80
80
80
80
170
Operating
Temp
T
opr
(ºC)
-25 ~ +80
-25 ~ +80
-25 ~ +80
-25 ~ +80
-25 ~ +80
-25 ~ +80
-25 ~ +80
-25 ~ +80
-25 ~ +80
Storage
Temp
T
stg
(ºC)
-40 ~ +40
-40 ~ +40
-40 ~ +40
-40 ~ +40
-40 ~ +40
-40 ~ +40
-40 ~ +40
-40 ~ +40
-40 ~ +40
52H
Series
Colour
* 1/10 Duty Cycle. 0.1 ms Pulse Width
Soldering Instructions
DIP and Wave Soldering
Types
Temp of
Soldering
Bath
≤
260 ºC
LEDs
≤
260 ºC
5S
>4mm
≤
300 ºC
5S
>4mm
Max
Soldering
Time
3S
Distance from
Solder Joint to
Case
>2mm
Iron Soldering (1.5 mm Iron Tip)
Temp of
Soldering
Iron
≤
300 ºC
Distance
Max
Soldering from Solder
to case
Time
3S
>2mm
Component Disposal Instructions
1. All Devices are RoHS compliant, customers are requested to please dispose as per prevailing Environmental
Legislation of their Country.
2. In Europe, please dispose as per EU Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE).
Disclaimer
The product information and the selection guides facilitate selection of the nxt LEDs best suited for application in your product(s) as per your requirement. It
is recommended that you completely review our Data Sheet(s) so as to confirm that the LED(s) meet functionality parameters for your application. The
information furnished in the Data Sheet and on the CDIL Web Site/CD are believed to be accurate and reliable. CDIL however, does not assume
responsibility for inaccuracies or incomplete information. Furthermore, CDIL does not assume liability whatsoever, arising out of the application or use of any
CDIL product; neither does it convey any license under its patent rights nor rights of others. These products are not designed for use in life saving/support
appliances or systems. CDIL customers selling these products (either as individual LEDs or incorporated in their end products), in any life saving/support
appliances or systems or applications do so at their own risk and CDIL will not be responsible for any damages resulting from such sale(s).CDIL strives for
continuous improvement and reserves the right to change the specifications of its products without prior notice.
CDIL is a registered Trademark of
Continental Device India Limited
C-120 Naraina Industrial Area, New Delhi 110 028, India.
Telephone + 91-11-2579 6150, 4141 1112 Fax + 91-11-2579 5290, 4141 1119
email@cdil.com
www.cdilsemi.com
52H_LEDRev100506D
Continental Device India Limited
Page 2 of 2
