ILB-1206
Vishay Dale
Multilayer Ferrite Beads
FEATURES
•
High reliability.
•
Surface mountable.
•
Magnetically self shielded.
• Nickel barrier plating virtually eliminates silver migration.
MECHANICAL SPECIFICATIONS*
Solderability:
90% coverage after 5 second dip in 235°C
solder following 60 second preheat at 120°C to 150°C and
type R flux dip.
Resistance To Solder Heat:
10 seconds in 260°C solder
after preheat and flux per above.
Terminal Strength:
1.0 kilograms (2.2 pounds) minimum
for 30 seconds.
Beam Strength:
2.0 kilograms (4.4 pounds) minimum.
ENVIRONMENTAL SPECIFICATIONS*
Operating Temperature:
- 55°C to + 125°C.
Thermal Shock:
300 cycles, - 40°C to + 125°C.
Biased Humidity:
85% RH at 85°C, 1000 hours at full rated
current.
STANDARD ELECTRICAL SPECIFICATIONS
IMPEDANCE
(Ohms)
19
26
31
50
60
70
80
90
100
120
150
200
300
500
600
800
1000
1200
1500
2000
TOL.
±
25%
±
25%
±
25%
±
25%
±
25%
±
25%
±
25%
±
25%
±
25%
±
25%
±
25%
±
25%
±
25%
±
25%
±
25%
±
25%
±
25%
±
25%
±
25%
±
25%
FREQUENCY
(MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
50
30
DCR
MAX.
(Ohms)
0.05
0.05
0.05
0.10
0.10
0.10
0.20
0.20
0.20
0.20
0.20
0.20
0.30
0.30
0.30
0.30
0.40
0.40
0.50
0.50
RATED DC
CURRENT
(mA)
500
500
500
600
600
600
400
400
400
400
300
300
300
200
200
200
200
100
100
100
DIMENSIONS
in inches [millimeters]
Dimensional Outline
B
Ferrite
Body
A
D
C
A
0.126
±
0.008
[3.20
±
0.2]
B
0.063
±
0.008
[1.6
±
0.2]
C
0.02
±
0.012
[0.5
±
0.3]
D
0.043
±
0.008
[1.1
±
0.2]
Suggested Pad Layout
G
PACKAGING OPTIONS
•
Bulk: 1,000 pieces per plastic bag.
•
Tape and Reel: Paper carrier tape, 3000 pieces per reel.
F
H
E
DESCRIPTION
ILB-1206
MODEL
19
Ω
IMPEDANCE VALUE
±
25%
IMPEDANCE TOLERANCE
E
0.173
[4.4]
F
0.055
[1.4]
G
0.087
[2.2]
H
0.043
[1.1]
SAP PART NUMBERING GUIDELINES (INTERNAL)
I
L
B
1
2
SIZE
0
6
R
K
1
9
IMPEDANCE
VALUE
0
V
TOL.
PRODUCT FAMILY
See the end of this data book for conversion tables
PACKAGE
CODE
www.vishay.com
86
For technical questions, contact Magnetics@vishay.com
Document Number 34023
Revision 15-Jan-03
ILB-1206
Multilayer Ferrite Beads
TAPE AND REEL SPECIFICATIONS
in inches [millimeters]
P
2
P
0
ØD
0
E
1
Vishay Dale
F
W
T
B
0
ØD
1
A
0
T
1
ØC
ØN
P
1
K
0
ØA
Empty Trailer
Components
W
1
Empty Tape
Cover Tape Leader
Unreel
Direction
160mm Minimum
160mm Minimum
390mm Minimum
A
0
B
0
D
0
D
1
E
1
F
K
0
P
0
P
1
0.071
±
0.008 [1.8
±
0.2]
0.14
±
.006 [3.45
±
0.15]
0.059 + .005/- 0.000 [1.5 + 0.127]
0.039 Min. [1.0 Min.]
0.069
±
.004 [1.75
±
0.1]
0.138
±
.002 [3.50
±
0.05]
0.049
±
.002 [1.24
±
0.05]
0.157
±
.004 [4.00
±
0.1]
0.157
±
.004 [4.00
±
0.1]
P
2
W
T
A
N
C
W
1
T
1
0.079
±
.002 [2.00
±
0.05]
0.327 Max. [8.3 Max.]
0.009
±
.002 [0.2
±
0.05]
7.000
±
.079 [178
±
2.0]
2.500 [63.5]
0.512
±
.020 [13.00 + 0.50]
0.315 + 0.059/- 0.00 [8.00 + 1.50]
0.079
±
.002 [2.00
±
0.05]
TYPICAL CURVES - FREQUENCY CHARACTERISTICS OF Z, X AND R
ILB-1206 19
Ω
35
Z
30
40
35
ILB-1206 26
Ω
IMPEDANCE (OHMS)
IMPEDANCE (OHMS)
Z
30
25
20
15
10
X
5
0
R
25
R
20
15
X
10
5
0
1
10
100
1000
10000
1
10
100
1000
10000
FREQUENCY (MHz)
FREQUENCY (MHz)
Document Number 34023
Revision 15-Jan-03
For technical questions, contact Magnetics@vishay.com
www.vishay.com
87
ILB-1206
Vishay Dale
Multilayer Ferrite Beads
TYPICAL CURVES - FREQUENCY CHARACTERISTICS OF Z, X AND R
ILB-1206 31
Ω
45
Z
40
ILB-1206 50
Ω
70
Z
IMPEDANCE (OHMS)
35
30
25
20
15
X
10
5
0
1
10
100
1000
10000
IMPEDANCE (OHMS)
R
60
R
50
40
30
20
X
10
0
1
10
100
1000
10000
FREQUENCY (MHz)
FREQUENCY (MHz)
ILB-1206 60
Ω
70
ILB-1206 70
Ω
90
Z
80
Z
60
IMPEDANCE (OHMS)
IMPEDANCE (OHMS)
R
70
60
50
40
30
20
10
0
X
R
50
40
30
20
X
10
0
1
10
100
1000
10000
1
10
100
1000
10000
FREQUENCY (MHz)
FREQUENCY (MHz)
ILB-1206 80
Ω
120
Z
160
140
ILB-1206 90
Ω
IMPEDANCE (OHMS)
IMPEDANCE (OHMS)
100
R
80
Z
120
R
100
80
60
40
X
20
60
40
20
X
0
1
10
100
1000
10000
0
1
10
100
1000
10000
FREQUENCY (MHz)
FREQUENCY (MHz)
www.vishay.com
88
For technical questions, contact Magnetics@vishay.com
Document Number 34023
Revision 15-Jan-03
ILB-1206
Multilayer Ferrite Beads
TYPICAL CURVES - FREQUENCY CHARACTERISTICS OF Z, X AND R
ILB-1206 100
Ω
160
Z
140
140
160
Z
Vishay Dale
ILB-1206 120
Ω
IMPEDANCE (OHMS)
IMPEDANCE (OHMS)
R
120
100
80
60
40
X
20
0
1
10
100
1000
10000
R
120
100
80
60
40
20
0
1
10
100
1000
10000
X
FREQUENCY (MHz)
FREQUENCY (MHz)
ILB-1206 150
Ω
200
180
Z
ILB-1206 200
Ω
250
Z
R
IMPEDANCE (OHMS)
160
R
140
120
100
80
60
40
X
20
0
1
10
100
1000
10000
IMPEDANCE (OHMS)
200
150
100
50
X
0
1
10
100
1000
10000
FREQUENCY (MHz)
FREQUENCY (MHz)
ILB-1206 300
Ω
400
Z
350
700
R
800
ILB-1206 500
Ω
IMPEDANCE (OHMS)
300
250
200
150
100
IMPEDANCE (OHMS)
600
Z
500
400
300
200
X
100
0
R
X
50
0
1
10
100
1000
10000
1
10
100
1000
10000
FREQUENCY (MHz)
FREQUENCY (MHz)
Document Number 34023
Revision 15-Jan-03
For technical questions, contact Magnetics@vishay.com
www.vishay.com
89
ILB-1206
Vishay Dale
Multilayer Ferrite Beads
TYPICAL CURVES - FREQUENCY CHARACTERISTICS OF Z, X AND R
ILB-1206 600
Ω
800
Z
700
700
800
ILB-1206 800
Ω
IMPEDANCE (OHMS)
IMPEDANCE (OHMS)
Z
600
R
500
400
300
200
X
100
0
600
R
500
400
300
200
X
100
0
1
10
100
1000
10000
1
10
100
1000
10000
FREQUENCY (MHz)
FREQUENCY (MHz)
ILB-1206 1000
Ω
2500
1200
ILB-1206 1200
Ω
IMPEDANCE (OHMS)
2000
Z
R
IMPEDANCE (OHMS)
1000
Z
800
R
1500
600
1000
400
X
200
500
X
0
1
10
100
1000
10000
0
1
10
100
1000
10000
FREQUENCY (MHz)
FREQUENCY (MHz)
ILB-1206 1500
Ω
2000
1800
ILB-1206 2000
Ω
2500
IMPEDANCE (OHMS)
IMPEDANCE (OHMS)
Z
R
1600
2000
Z
R
1400
1200
1000
800
600
400
1500
1000
500
X
200
0
1
10
100
1000
10000
X
0
1
10
100
1000
10000
FREQUENCY (MHz)
FREQUENCY (MHz)
www.vishay.com
90
For technical questions, contact Magnetics@vishay.com
Document Number 34023
Revision 15-Jan-03
