5962-9176402M3A datasheet, PDF

Datasheet> All Categories > Analog mixed-signal IC> converter> 5962-9176402M3A

5962-9176402M3A: DescriptionQUAD, PARALLEL, WORD INPUT LOADING, 6 us SETTLING TIME, 12-BIT DAC, CQCC28, HERMETIC SEALED, CERAMIC, LCC-28; CategoryAnalog mixed-signal IC converter; File Size850KB，7 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

5962-9176402M3A Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	5962-9176402M3A	-	-	View	Buy Now

5962-9176402M3A Overview

QUAD, PARALLEL, WORD INPUT LOADING, 6 us SETTLING TIME, 12-BIT DAC, CQCC28, HERMETIC SEALED, CERAMIC, LCC-28

5962-9176402M3A Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Parts packaging code	QLCC
package instruction	QCCN,
Contacts	28
Reach Compliance Code	unknown
Maximum analog output voltage	9.9853 V
Minimum analog output voltage	-9.9902 V
Converter type	D/A CONVERTER
Enter bit code	BINARY
Input format	PARALLEL, WORD
JESD-30 code	S-CQCC-N28
JESD-609 code	e0
length	11.43 mm
Maximum linear error (EL)	0.0366%
Humidity sensitivity level	NOT APPLICABLE
Nominal negative supply voltage	-15 V
Number of digits	12
Number of functions	4
Number of terminals	28
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	QCCN
Package shape	SQUARE
Package form	CHIP CARRIER
Peak Reflow Temperature (Celsius)	NOT APPLICABLE
Certification status	MILITARY
Filter level	MIL-STD-883
Maximum seat height	2.54 mm
Nominal settling time (tstl)	6 µs
Nominal supply voltage	15 V
surface mount	YES
technology	BICMOS
Temperature level	MILITARY
Terminal surface	TIN LEAD
Terminal form	NO LEAD
Terminal pitch	1.27 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	NOT APPLICABLE
width	11.43 mm
Base Number Matches	1
