BUS-61560-100 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> BUS-61560-100

BUS-61560-100: DescriptionMil-Std-1553 Controller, 2 Channel(s), 0.125MBps, CMOS, DIP-78; CategoryThe embedded processor and controller Microcontrollers and processors; File Size95KB，2 Pages; ManufacturerData Device Corporation

Download Datasheet Parametric Compare View All

BUS-61560-100 Overview

Mil-Std-1553 Controller, 2 Channel(s), 0.125MBps, CMOS, DIP-78

BUS-61560-100 Parametric

Parameter Name	Attribute value
Maker	Data Device Corporation
Parts packaging code	QIP
package instruction	QIP,
Contacts	78
Reach Compliance Code	unknown
Address bus width	16
boundary scan	NO
letter of agreement	MIL-STD-1553B
Data encoding/decoding methods	NRZ
Maximum data transfer rate	0.125 MBps
External data bus width	16
JESD-30 code	R-XQIP-P78
low power mode	NO
Number of serial I/Os	2
Number of terminals	78
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	UNSPECIFIED
encapsulated code	QIP
Package shape	RECTANGULAR
Package form	IN-LINE
Certification status	Not Qualified
Maximum seat height	5.334 mm
Nominal supply voltage	5 V
surface mount	NO
technology	CMOS
Temperature level	MILITARY
Terminal form	PIN/PEG
Terminal pitch	2.54 mm
Terminal location	QUAD
width	41.91 mm
uPs/uCs/peripheral integrated circuit type	SERIAL IO/COMMUNICATION CONTROLLER, MIL-STD-1553
Base Number Matches	1

Preview

Download Datasheet

View All

BUS-61560-100 Related Products

	BUS-61560-100	BUS-61559-100	BUS-61569-100
Description	Mil-Std-1553 Controller, 2 Channel(s), 0.125MBps, CMOS, DIP-78	Mil-Std-1553 Controller, 2 Channel(s), 0.125MBps, CMOS, DDIP-78	Mil-Std-1553 Controller, 2 Channel(s), 0.125MBps, CMOS, FP-82
Maker	Data Device Corporation	Data Device Corporation	Data Device Corporation
Parts packaging code	QIP	QIP	DFP
package instruction	QIP,	QIP,	DFP,
Contacts	78	78	82
Reach Compliance Code	unknown	unknown	unknown
Address bus width	16	16	16
boundary scan	NO	NO	NO
letter of agreement	MIL-STD-1553B	MIL-STD-1553B	MIL-STD-1553B
Data encoding/decoding methods	NRZ	NRZ	NRZ
Maximum data transfer rate	0.125 MBps	0.125 MBps	0.125 MBps
External data bus width	16	16	16
JESD-30 code	R-XQIP-P78	R-XQIP-P78	R-XDFP-F82
low power mode	NO	NO	NO
Number of serial I/Os	2	2	2
Number of terminals	78	78	82
Maximum operating temperature	125 °C	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C
Package body material	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED
encapsulated code	QIP	QIP	DFP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	IN-LINE	FLATPACK
Certification status	Not Qualified	Not Qualified	Not Qualified
Nominal supply voltage	5 V	5 V	5 V
surface mount	NO	NO	YES
technology	CMOS	CMOS	CMOS
Temperature level	MILITARY	MILITARY	MILITARY
Terminal form	PIN/PEG	PIN/PEG	FLAT
Terminal location	QUAD	QUAD	DUAL
uPs/uCs/peripheral integrated circuit type	SERIAL IO/COMMUNICATION CONTROLLER, MIL-STD-1553	SERIAL IO/COMMUNICATION CONTROLLER, MIL-STD-1553	SERIAL IO/COMMUNICATION CONTROLLER, MIL-STD-1553
Maximum seat height	5.334 mm	5.334 mm	-
Terminal pitch	2.54 mm	2.54 mm	-
width	41.91 mm	41.91 mm	-
Base Number Matches	1	1	-
