D IM E N S IO N S IN IN C H E S - D O N O T S C A L E T H IS D R A W IN G
D IM E N S IO N S IN M E T R IC - [ ]
O R IE N T A T IO N
M A R K E T IN G
S A L E S D R A W IN G
E le
p e r T
te s t p la
T
T e s tin g
s ta n d a rd
M il-S td -2 0 2
th o d s .
C IR C U IT
1 .2 5 0 ± .0 3 1
[3 1 .7 5 ± 0 .7 9 ]
.2 5 0
[6 .3 5 ]
R E F .
.6 2 5
[1 5 .8 7 ]
.1 2 5
[3 .1 7 ]
.3 7 5
[9 .5 2 ]
.3 1 2
[7 .9 2 ]
# 1 6 A W G .
(Ø .0 5 1 [1 .3 0 ]
T IN N E D C O P P E R )
.0 6 3 [1 .6 0 ]
.3 4 4
[8 .7 4 ]
# 1 2 -2 8 U N F -2 A
T H R E A D
.1 6 6
[4 .2 2 ]
M A X IM U M
T IG H T E N IN G
T O R Q U E - 8 IN . L B S .
T U S O N IX S T Y L E
C A P . V A L U E
C A P . T O L .
T E M P . C O E F .
V O L T . R A T IN G
O P E R A T IN G T E M P . R A N G E
3 2 1 -0 1 0
2 0 0 0 p F
± 2 0 %
X 5 U
5 0 0 V D C
-5 5 T O + 8 5 ° C
N O T E :
1 . S U P P L IE D W IT H S IL V E R H E X N U T A N D L O C K W A S H E R .
X -2 0 1 5 R e v -0
R E V IS IO N R E C O R D
O r ig in a l R e le a s e
C .O .
2 0 0 8 0 2 1 2 - 1 - 0 1
--T O L E R A N C E S --
U n le s s O th e r w is e
S p e c ifie d
D E C IM A L ±
A N G L E S ±
.0 1 5 [0 .3 8 ]
T itle
F E E D -T H R U
C A P A C IT O R
S .M . 0 2 -1 2 -0 8
R .L . 0 2 -1 2 -0 8
S c a le
4 X
0
D ra w n
A p p ro v e d
T U C S O N , A R IZ O N A
A
3 2 1 -0 1 0 -X 5 U 0 -2 0 2 M
