5223110-1 Product Details
Live Product Chat
Product View
2mm Centerline Futurebus+ Connectors
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
5223110-1
T E I nternal N umber: 5 2 2 3 1 1 0 - 1
Product Highlights:
l
Module Type = Power and Signal
l
180 Signal Positions
l
10 Power Positions
l
Free-Board (Receptacle)
l
PC B Mount Angle = Right Angle
View all Features
Pending Obsolescence
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
C onnector, Z-PAC K*, 2 mm FB, Signal and Power
(PDF, English)
Application Specifications:
l
Z-PAC K 2mm FB (Futurebus+) Receptacle and Pin Header...
(PDF, English)
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Free-Board (Receptacle)
l
PC B Mount Angle
= Right Angle
l
Post Type
= Press-Fit
l
C omment = Organizer on power leads.
Mechanical Attachment:
l
Module Type
= Power and Signal
l
Number of Power Positions
= 10
l
Press-Fit Post Style = C ompliant Pin
Electrical Characteristics:
l
Voltage Rating (VAC ) = 30
Termination Related Features:
l
Termination Post Length (mm [in])
= 3.56 [0.140]
Body Related Features:
l
Number of Signal Positions
= 180
l
Sequencing
= No
l
Number of Rows
= 5
l
Post Plating
= Tin
l
C enterline, Matrix (mm [in]) = 2.00 x 2.00 [.079 x .079]
l
Selectively Loaded = No
Contact Related Features:
l
C ontact Base Material = C opper Alloy
l
C ontact Mating Area Plating Material = Gold (30)
Housing Related Features:
l
Housing Material = Liquid C rystal Polymer (LC P)
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
