Power Cord with IEC Connector C9, Straight
306
C9
70° C
Description
Approvals
Power Supply Cord / Interconnection Cord, Protection class II, Pin tem-
perature 70 °C, Cable
- UL File Number: E45116
- CSA File Number: 27325
Technical Data
Ratings IEC
Ratings UL/CSA
Dielectric Strength
Terminal
Material: Housing
Dimensions
13.8
SE
20.4 mm
Allowable Operation Temp.
Degree of Protection
Protection Class
6 A / 250 VAC; 50 Hz
6 A / 250 VAC; 60 Hz
> 3 kVDC between L-N
> 1.5 kVAC between L/N-PE
(1 min/50 Hz)
-25 °C to 70 °C
from front side IP 20 acc. to IEC 60529
Suitable for appliances with protection
class 2 acc. to IEC 61140
moulded
PVC, black or grey
PH
A
20.4
10.4
Connectors
-O
UT
Weblinks
Connector
C9 acc. to IEC/EN 60320-1
UL 498, CSA C22.2 no. 42 (for cold
conditions) pin-temperature 70 °C, 6 A,
Protection Class 2
pdf, html, General Product Information, Approvals, RoHS, CHINA-RoHS,
Mating Connectors, e-Shop, SCHURTER-Stock-Check, Distributor-
Stock-Check, Accessories, Detailed request for product
61.5
306
www.schurter.com/pg07_2
Config. Code
Type
|
-
|
R
|
-
|
3016
|
-
|
D
|
-
|
Length
|
The characters are placeholders for the correspondingly keys of selections from the key tables.
Typ is placed for the connector type on the second end, length is the cord length in mm.
Cord Sets
Cord end 2
zzzz,
2225, 2228, 2343, 419C, 4190, 4191, 607B, 608B, 609B
Type
|
-
|
R
|
-
|
3016
|
-
|
D
|
-
|
Length
|
= cord type
cord type
H03VV-F 2x0,75mm2
H03VVH2-F 2x0,75mm2
H05VV-F 2x0,75mm2
H05VVH2-F 2x0,75mm2
SVT 2x18AWG
Cord definition is detailed in general product information
XXX
Configuration
key
A
B
E
M
D
Mating Inlets/Plugs
Category / Description
AS
Appliance Inlet further types to3016
Appliance Inlet Overview complete
IEC Appliance Inlet C10, Screw-on Mounting, Front or Rear Side, Solder or Quick-connect Terminal
IEC Appliance Inlet C10, Screw-on Mounting, Front Side, Solder or Quick-connect Terminal
IEC Appliance Inlet C10, Screw-on Mounting, Front Side, Solder or Quick-connect Terminal
E-
Cord length in mm
6058
6075
6076
PH
2
The specifications, descriptions and illustrations indicated in this document are based on
Connectors
current information. All content is subject to modifications and amendments.
25.09.2012
OU
T
Type
|
-
|
R
|
-
|
3016
|
-
|
D
|
-
|
Length
|
= Color
Color
Black
Configuration
key
A
Grey
B
Type
|
-
|
R
|
-
|
3016
|
-
|
D
|
-
|
Length
|
= Cord end 2
Type
|
-
|
R
|
-
|
3016
|
-
|
D
|
-
|
Length
|
= Cord length
Cord length
zzzz, 000500, 001000, 001500, 002000, 002500, 003000, 005000
