Ultra-low Ohmic Resistors for Current Detection(Wide terminal type)
PML18
Features
1) Ultra-low resistance range
2) Wide terminal configuration for high joint reliability.
3) Unique trimless structure utilized for improved current detection accuracy.
4) ISO9001- / ISO/TS 16949- approved
Rating
Item
Rated power
Conditions
For resistors operated at the ambient temperature in
excess of 70°C, the load shall be derated in accordance with Fig.1
100
80
POWER LOAD (%)
Specifications
1W
at 70°C
60
40
20
0
−55
0
70
100
125
155
AMBIENT TEMPERATURE (°C)
Fig.1
Rated voltage
Rated current
Rated voltage and current are determined from the following.
E= P×R
E= P / R
Nominal resistance
Operating temperature
See Table 1.
−55°C
to
+155°C
E: Rated voltage (V)
I : Rated current (A)
P: Rated power (W)
R: Resistance (Ω)
Table.1
RESISTANCE
(mΩ)
0.5, 1.0, 1.2
1.5, 1.8, 2.0
2.4, 2.5
G (±2%)
J (±5%)
V
±150
TOLERANCE
SPECIAL
CODE
TEMPERATURE (ppm / ˚C)
COEFFICIENT
www.rohm.com
c
○
2011 ROHM Co., Ltd. All rights reserved.
1/3
2011.10 Rev.B
PML18
Characteristics
Item
Resistance
Guaranteed value
Resistor type
G :
±2%
J :
±5%
Test conditions (JIS C 5201-1)
JIS C 5201-1 4.5
Measuring method : Measure under
terminations by 4 probes.
Fig.2 (Under terminations)
probes
Data Sheet
Variation of resistance
with temperature
Overload
See Table.1
±
2.0%
A new uniform coating of minimum of
95% of the surface being immersed
and no soldering damage.
±
1.0%
No remarkable abnormality on the appearance.
±
1.0%
±
3.0%
JIS C 5201-1 4.8
Measurement :
+25
/
−55
/
+25
/
+125°C
JIS C 5201-1 4.13
Rated voltage (current)
×2.5,
2s.
JIS C 5201-1 4.17
Rosin·Ethanol (25%WT)
Soldering condition : 235±5°C
Duration of immersion : 2.0±0.5s.
JIS C 5201-1 4.18
Soldering condition : 260±5°C
Duration of immersion : 10±1s.
JIS C 5201-1 4.19
Test temp. :
−55°C
to
+125°C
5cyc
JIS C 5201-1 4.24
40°C, 93%RH
Test time : 56days
JIS C 5201-1 4.25.1
70°C, Rated power
1.5h : ON
−
0.5h : OFF
Test time : 1,000h to 1,048h
JIS C 5201-1 4.25.3
155°C
Test time : 1,000h to 1,048h
JIS C 5201-1 4.29
23°C±5°C
Solvent : 2-propanol
JIS C 5201-1 4.33
Solderability
Resistance to
soldering heat
Rapid change of
temperature
Damp heat, steady state
±
3.0%
Endurance at 70°C
±
3.0%
Endurance
Component Solvent
Resistance
Bend strength of
the end face plating
±
0.5%
Without open.
www.rohm.com
c
○
2011 ROHM Co., Ltd. All rights reserved.
2/3
2011.10 Rev.B
