Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207
Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com
Customer Specification
PART NO. 45462
Construction
Diameters (In)
1) Component 1
a) Conductor
b) Insulation
(1) Color Code
Cond
1
2) Cable Assembly
a) Twists:
b) Core Wrap
3) Shield:
a) Foil Direction
b) Drain Wire
4) Jacket
a) Color(s)
b) Ripcord
Color
BLACK
2 X 1 COND
20 (7/28) AWG TC
0.016" Wall, Nom. TPE
Alpha Wire Color Code D
Cond
2
2 Components Cabled
8.0 Twists/foot (min)
Nonwoven Polyester Tape, 25% Overlap, Min.
Alum/Mylar Tape, 25% Overlap, Min.
Foil Facing In
20 (7/28) AWG TC
0.045" Wall, Nom.,TPE
0.238 (0.248 Max.)
Color
RED
Cond
Color
0.038
0.070
Slate, Black, Yellow, Orange, Blue, Green, Red, Sand Beige, White
1 End 810 Denier Nylon
ALPHA WIRE-* P/N 45462 2C 20 AWG
XTRAGUARD(R) 4 (UL) TYPE PLTC 105C OR AWM 20237
125C 300 VOLTS -- LLXXXXX CSA AWM I/II A/B
c) Print
125C 300 VOLTS FT1 P-07-KA070017-MSHA
CE (SEQ FOOTAGE)
* = Factory Code
[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]
Applicable Specifications
1) UL
AWM/STYLE 20237
PLTC
2) CSA International
AWM I/II A/B
FT1
3) Other
4) CE:
PENNSYLVANIA BUREAU OF MINE SAFETY
APPROVED
EU Low Voltage Directive 2006/95/EC
125°C / 300 VRMS
105°C
125°C / 300 VRMS
Environmental
1) California Proposition 65:
The outer surface materials used in the manufacture of this part meet the requirements of
California Proposition 65.
Properties
Physical & Mechanical Properties
1) Temperature Range
2) Bend Radius
3) Pull Tension
4) Sunlight Resistance
Electrical Properties
1) Voltage Rating
2) Capacitance
3) Ground Capacitance
4) Characteristic Impedance
5) Inductance
6) Conductor DCR
7) OA Shield DCR
-50 to 125°C
10X Cable Diameter
26 Lbs, Maximum
Yes
(For Engineering purposes only)
300 VRMS
23.8 pf/ft @1 kHz, Nominal Conductor to Conductor
43 pf/ft @1 kHz, Nominal
66 Ω
0.19 µH/ft, Nominal
10.2 Ω/1000ft @20°C, Nominal
8.2 Ω/1000ft @20°C, Nominal
Other
Packaging
a) 1000 FT
b) 500 FT
c) Bulk(Made-to-order)
Flange x Traverse x Barrel (inches)
12 x 12 x 3.5 Continuous length
12 x 6 x 3.5 Continuous length
[Spool dimensions may vary slightly]
