Module no:3006690 LabelId:3006690 Operator:Phoenix
18:52:40, Donnerstag, 28. Juni 2001
ZFK 1,5-TWIN
Terminal width 4.2
(IEC)
[mm ]
IEC 947-7-1
2
rigid
solid
flexible
stranded AWG
I
[A]
17.5*
U
[V]
500
0.14-1.5 0.14-1.5 26-16
* The max. load current must not be exceeded by the residual current of all connected conductors.
Description
Spring cage terminal block,
for mounting on
3
Color
gray
blue
Accessories
(1)
End cover
(3)
Fixed bridge,
for
cross-connections in the
terminal center, divisible,
screw heads with insulation
collars
(5)
Separating plate,
for
electrical separation of
neighboring bridges, can be
fitted later, no loss of pitch
(6)
Partition plate,
for optical
and electrical separation of
terminal block groups, 2 mm
thick
(7)
Test plugs,
assembled as a block of 10
(8)
Screwdriver,
for
actuating the tension spring
(9)
Actuation tool,
for
actuating the tension spring
(10)
Zack marker sheet, flat,
100 or 120-section, for
labelling the outer marker
grooves
2-pos.
3-pos.
gray
2-pos.
3-pos.
10-pos.
D-ZFK 2,5-TWIN
FBRN 2-4 N
FBRN 3-4 N
FBRN 10-4 N
TS-U3K 2,5
30 02 80 1
I
max.
: 17.5 A
30 01 54 3
17.5 A
30 01 55 6
17.5 A
30 01 62 4
27 70 06 6
50
10
10
10
100
Type
ZFK 1,5-TWIN
ZFK 1,5-TWIN BU
Order No.
30 06 69 0
30 06 68 7
Pcs.
Pkt.
50
50
ATP-ZFK 2,5-TWIN
30 03 99 4
50
PS-ZFK 1,5
SZF 0 - 0,4 x 2,5
ZFK-BW 2-4
ZFK-BW 3-4
ZBFM 4
(see
info)
30 00 96 8
12 04 50 4
30 24 25 8
30 24 26 1
10
1
1
1
Phoenix Contact Elektronischer Katalog
Page 1 / 2
Module no:3006690 LabelId:3006690 Operator:Phoenix
Technical data
Dimensions
Width / length / end cover width
Height (NS 35:7.5 / NS 35:15)
Technical data in accordance with IEC/ DIN VDE
Maximum load current / cross section
Rated surge voltage / contamination class
Surge voltage category / insulation material
group
Connection capacity
stranded with ferrule with plastic sleeve
stranded with ferrule without plastic sleeve
stranded with TWIN ferrule with plastic
sleeve
Stripping length
Internal cylindrical gage (IEC 947-1:1988)
Insulation material
Inflammability class acc. to UL 94
Temperature indices RTI / Ti
Block diagram
[mm ]
[mm ]
[mm ]
[mm]
2
2
2
18:52:40, Donnerstag, 28. Juni 2001
[mm]
[mm]
4.2 / 71 / 2
37.5 / 45
17.5 / 1.5
6/3
III / I
[A] / [mm ]
[kV] / –
–/–
2
0.25 - 1.5
0.25 - 1.5
0.5
10
A1
PA
V0
130 / 120
Phoenix Contact Elektronischer Katalog
Page 2 / 2
