OC3-T-25000X-H-C-A-2-R-X

Description
CRYSTAL OSCILLATOR, CLOCK, HCMOS OUTPUT
CategoryPassive components    oscillator
File Size443KB,3 Pages
ManufacturerPrecision Devices Incorporated
Environmental Compliance
Download Datasheet Parametric View All

OC3-T-25000X-H-C-A-2-R-X Overview

CRYSTAL OSCILLATOR, CLOCK, HCMOS OUTPUT

OC3-T-25000X-H-C-A-2-R-X Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerPrecision Devices Incorporated
Reach Compliance Codeunknown
Other featuresTRI-STATE; ENABLE/DISABLE FUNCTION; TR, 7 INCH
maximum descent time6 ns
Frequency Adjustment - MechanicalNO
frequency stability50%
JESD-609 codee4
Installation featuresSURFACE MOUNT
Nominal operating frequency25 MHz
Maximum operating temperature70 °C
Minimum operating temperature
Oscillator typeHCMOS
Output load10 TTL, 15 pF
physical size3.2mm x 2.5mm x 1.0mm
longest rise time6 ns
Maximum supply voltage2.75 V
Minimum supply voltage2.25 V
Nominal supply voltage2.5 V
surface mountYES
maximum symmetry60/40 %
Terminal surfaceGold (Au)
Base Number Matches1
OC3-Series Specifications
3.20L x 2.50W x 1.00H (mm)
PDI Model
OC3-Series
provides precision timing in a hermetically
sealed package, and is available in both standard and custom frequencies
and configurations. PDI provides quick-turn sampling for your proto-typing
needs, mass production capability, and competitive pricing.
ex)
OC3—T—25000X—C—D—A—3—R—X
*
ENABLE
T
= Tri-State
N
= No/Connect
FREQUENCY
00030X-80000X
=
0.0300 MHz –
80.000 MHz
OUTPUT
C
= TTL/CMOS
O
= LVCMOS
H
= HCMOS
FREQUENCY
STABILITY
B
= ±25 **
C
= ±50
D
= ±100
S
= Special
OPERATING
TEMPERATURE
A
= 0 to +70°C
B
= -20 to +70°C
D
= -40 to +85°C
E
= -55 to +125°C
S
= Special
SUPPLY
VOLTAGE
1
= 1.8
2
= 2.5
F
= 3.0
3
= 3.3
PACKAGE
R
= Tape & Reel
** - Not available -55 to +125°C
* - for standard or assigned for customization.
Parameter
Frequency Range
Frequency Stability
*1
Temperature Range
*1
*1
Supply Voltage
*1
(±10%)
3.3
3.0
2.5
1.8
*2
Units
V
MHz
ppm
°C
°C
Supply Current (Maximum)
Output
Load
Duty Cycle (at 50% Vcc)
Rise/Fall Times (Maximum)
Start up Time (Maximum)
Output Voltage Levels
All Causes (Maximum )
Operating
Storage
0.030000 to 9.999999 MHz
10.000000 to 34.999999 MHz
35.000000 to 49.999999 MHz
50.000000 to 80.000000 MHz
15
20
35
40
Rise Time (10% to 90% Vcc)
Fall Time (90% to 10% Vcc)
High (Minimum)
Low (Maximum)
High (See below) or Open
Low (See below)
*3
High Value (Minimum)
Low Value (Maximum)
*3
Disable Current (Maximum)
*3
Enable Delay Time (Maximum)
Disable Delay Time (Maximum)
7
7
Pin 1 (Tri-State) (Option)
80
20
10
0.030000 to 80.000000
Per Option
Per Option
- 55 to +125
8
7
10
8
25
20
35
30
Per Option
15pF/10 TTL gates
40 to 60% (45 to 55% option)
7
6
7
6
10
90
10
Enable
Disable
80
80
20
20
10
10
10
150
6
7
15
25
mA
5
5
ns
ms
% Vcc
80
20
10
% Vcc
% Vcc
uA
ms
ns
*1 - Not all Frequency/Temperature/Voltage combinations are available.
*2 - Inclusive of Tolerance @25°C, Operating Temperature, Supply Voltage, Load, Aging, Shock and Vibration.
*3 - Internal crystal oscillation halted.
REV:
NA
SIZE:
A
CAGE:
0S4G1
1
of
3
