EAS, EBS
Snap-in
Compact RFI Filter
IEC Connector Package
Series
UL Recognized
CSA Certified
VDE Approved
EAS Series
This filter offers the performance characteristics of the
EEA susceptibility filter with the additional advantage of a
snap-in panel mount. The EAS series supersedes the EF
series by providing superior performance, particularly in
the common mode at low frequencies.
Specifications
Maximum leakage current, each
line-to-ground
@ 120 VAC 60 Hz:
@ 250 VAC 50 Hz:
Hipot rating (one minute):
line-to-ground
line-to-line
Operating frequency:
Rated voltage:
.22mA
.38mA
1500 VAC
1450 VDC
50/60 Hz
120/250 VAC
EBS Series
This filter offers the performance characteristics of the
EEB susceptibility filter with the additional advantage of
a snap-in panel mount. The EBS provides enhanced
differential mode performance compared to both the EAS
and EF series.
Minimum
insertion loss in dB:
EAS
Line-to-ground in 50 ohm circuit
Current
Frequency-MHz
Rating
.01 .05 .1 .15 .5
1
5
1A
12 23 29 32 41 47 47
3A
-
10 15 19 30 36 48
6A
-
1
4 10 22 28 42
10A
-
1
3
5 14 20 32
15A
-
-
-
1
5
8
20
Line-to-line in 50 ohm circuit
Resistor location for reference only.
Electrical Schematic
10
47
50
48
38
26
30
40
47
47
47
40
Current
Rating
1A
3A
6A
10A
15A
.5
1
2
2
1
1
Frequency-MHz
1
1.5
3
5
9
4
4
4
4
19
6
6
5
6
32
20
6
5
12
42
35
24
5
14
10
45
45
40
30
15
30
40
40
40
40
40
AS
BS
22
EBS
Line-to-ground in 50 ohm circuit
Current
Frequency-MHz
Rating
.01 .05
.1 .15 .5
1
5
1A
12 23 29 32 41 47 47
3A
-
10 14 18 30 36 48
6A
-
1
4 10 22 28 42
10A
-
1
3
5 14 20 32
15A
-
-
-
1 5
8
20
Line-to-line
Current
Rating
1A
3A
6A
10A
15A
in 50 ohm circuit
Frequency-MHz
.01 .15 .5
1
3
5
1
3
14
23
41
1
2
11
14
25
1
2
10
14
20
1
2
10
16
19
-
2
10
16
24
10
47
50
48
38
26
30
40
47
47
47
40
10
47
38
33
19
28
30
50
44
42
39
28
44
40
40
40
40
Libertyville, IL (847) 680-7400
Series
EAS,
Case Style
Metric shown in italics.
EBS
D
± .010
± .25
Case Dimensions
Metric shown in italics.
EAS1/EBS1
Part No.
EAS1
EBS1
A
(max)
2.2
55.88
2.2
55.88
B
(max)
1.15
29.2
1.15
29.2
C
(max)
.9
22.86
.9
22.86
E
(max)
1.35
34.21
1.35
34.21
1.185
30.1
1.185
30.1
Ordering Information
Consult your local Corcom sales representative for pricing.
Typical dimensions
Terminals:
.25
6.35
(3)
Holes:
.
07
Dia.(2)
1.8
Slots:
.
07 x .16
1.8 x 4.1
Available Part Numbers
1EAS1
3EAS1
6EAS1
10EAS1
15EAS1
1EBS1
3EBS1
6EBS1
10EBS1
15EBS1
Recommended Panel Cutout
Accessory Line Cord No. GA400
7 1/2 foot, 3 conductor line cord to mate with filter IEC
input connector. 1250 watt, 10A-125 VAC, black SVT
cord, UL listed, CSA certified
Accessory Insulating Boot No. FA601
Plastic shroud to cover terminals on back of filter
(style 1 terminals only)
Front Mount Only
Panel Thickness .031" - .047"
(.78
mm - 1.19 mm)
EAS
EBS
23
Libertyville, IL (847) 680-7400
