TABLE OF CONTENTS
L
SHEET NO.
1
2
3
SHEET DESCRIPTION
NOTES AND BOM
CONFIGURATIONS
RECEPTACLE CONNECTOR ASSEMBLY
K
PART NUMBER
349674001
349674002
349674003
349674004
349674021
349674005
349674006
349674007
349674008
349674025
KEY
A
B
C
D
A
A
B
C
D
A
PART NUMBER AND MATING INTERFACE CHART
COVER COLOR
TERMINAL POSITIONS PLUGGED
BLACK
NONE
LIGHT GRAY
NONE
DARK GRAY
NONE
STONE GRAY
NONE
2
BLACK
BLACK
NONE
LIGHT GRAY
NONE
DARK GRAY
NONE
STONE GRAY
NONE
2
BLACK
CPA INCLUDED
YES
YES
YES
YES
YES
NO
NO
NO
NO
NO
INTERFACE PART NUMER
349684801
349684802
349684803
349684804
349684801
349684801
349684802
349684803
349684804
349684801
L
K
J
J
TERMINAL POSITION 1
TERMINAL POSITION 4
CONNECTOR POSITION ASSURNCE (CPA)
NOTES: VALID UNLESS OTHERWISE SPECIFIED
H
1X4
1. GENERAL:
A. APPLICATION SPECIFICATION SEE: AS-34894-0001
-CONTAINS: PRODUCT INTRODUCTION, PRODUCT SUMMARY,
CONNECTOR ASSEMBLY, PACKAGING INFORMATION, CONNECTOR
MATING, SERVICE INSTRUCTIONS, ELECTRICAL CONTINUITY
CHECKING, CRIMPING, AND TROUBLESHOOTING.
B. TERMINALS TO BE USED WITH THIS ASSEMBLY:
TERMINAL TABLE
TERMINAL
PART
NUMBER
TOP
MARKING
LAYER
TYPE
PLATING
TYPE
LH
Ag
L
Sn
Ag
SH
S
Sn
H
CONNECTOR HOUSING
G
1.80
PITCH
WIRE
WIRE
MAX
GRIP
INSULATION
SIZE
MAX VOLTAGE
TEMP.
CODE
OD (mm)
(mm²)
G
MAT SEAL
F
34905-3443
34905-2443
34905-3444
34905-2444
L
S
1.2-1.4
0.35
0.13
0.95-1.05
125°C
105°C
14 VOLTS DC
125°C
105°C
RING SEAL
F
E
D
FOR MORE INFORMATION ON TERMINALS SEE MOLEX DRAWING 349050400 AND TERMINAL
PRODUCT SPECIFICATION PS-34905-001.
C. CONNECTOR PRODUCT SPECIFICATION SEE 349670001 PS
CONTAINS: PRODUCT INTRODUCTION, PRODUCT SUMMARY,
RATINGS AND PRODUCT VALIDATION.
VALIDATED TO USCAR 2 REV 6.
RATINGS: T3 V1 S2
D. DESIGNED TO MATE WITH DEVICE INTERFACE AS SPECIFIED IN PART NUMBER AND INTERFACE
CHART. SEE MOLEX DRAWING 349684800 FOR INTERFACE SPECIFICATION.
E. ASSEMBLY SHIPPED WITH ISL IN PRE-LOCK POSITION (SEE ISL PRE-LOCK VIEW SHEET 3).
F. PACKAGING SPECIFICATION PER MOLEX DRAWING: PK-31301-898
G. PARTS MUST BE IN COMPLIANCE TO MOLEX CHEMICAL SUBSTANCES FOR
PRODUCTS AND PACKAGING SPECIFICATION: ES-40000-5016
COVER
H. DATA MUST BE SUBMITTED UNDER THE MOLEX PART NUMBER TO IMDS
(COMPANY ID#13255)
2. DESIGN - MATERIALS:
CONNECTOR HOUSING: SPS/NYLON GF20 BLACK
TERMINAL HOUSING:
SPS/NYLON GF20 BLACK
COVER:
SPS/NYLON GF20 COLORS IN PART NUMBER CHART
ISL:
SPS GF30 NATURAL
MAT SEAL:
INHERENTLY LUBRICATED SILICONE LIGHT BLUE
RING SEAL:
INHERENTLY LUBRICATED SILICONE RUST RED
CPA (OPTIONAL):
PBT GF30 RED
3. DESIGN - GEOMETRY:
A. ALL GRAPHIC DATA IS BASIC (NO TOLERANCE) AND MUST BE TAKEN FROM
THE DATA FILE AT ITS LATEST REVISION.
B. GEOMETRIC DIMENSIONS AND TOLERANCES PER ASME Y14.5M-2009
C. EDGES AND UNDIMENSIONED DETAILS PER ISO13715
D. CORNERS SHOWN AS SHARP TO BE R 0.2 MAX.
E. LETTERING SHALL BE 0.15 MAX RAISED IN 0.25 MAX RECESS PAD.
THIS INCLUDES RECYCLING CODE, CAVITY ID, VENDOR IDENTIFICATION,
AND CUSTOMER MATERIAL NUMBER.
F. VISUAL DEFECTS SHALL MEET COSMETIC STANDARD PS-45499-002 (Class B).
G. PARTS ARE LASER MARKED WITH PART NUMBER AND DATE CODE
TERMINAL HOUSING
E
TERMINAL HOUSING RIBS ADDED
UPDATED INFORMATION IN NOTES
COVER GEOMETRY UPDATE,
TOLERANCE CHANGES, NOTES
CHANGES
E
D1
D
C2
C1
C
B2
B2
B1
B
A1
A
INDEPENDENT SECONDARY LOCK (ISL)
C
UPDATED PART NUMBER CHART
CORRECTIONS & CLARIFICATIONS
GEOMETRY CHANGES
ADDED LASER MARKING LOCATION
UPDATED INTERFACE CHART
UPDATED INTERFACE LAYOUT
COMPONENT MODEL UPDATE
UPDATED VIEWS & INTERFACE CHART
MINOR UPDATES
INITIAL RELEASE
REV DESCRIPTION
D
C
INSPECTION NUMBER LOG
LAST NUMBER: 15
ADDED:
REMOVED: 2,4,7,8,9,13,14
2017/06/27
1
REV
B
=
=
=
=
=
=
=
0
0
0
2017/07/10
QUALITY
SYMBOLS
THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
DIMENSION UNITS
SCALE
GENERAL
B
TOLERANCES
MM
1:1
(UNLESS SPECIFIED)
DRWN BY
DATE
ANGULAR TOL ±
3.0
°
MNS02
CHK'D BY
DATE
2016/04/26
4 PLACES
3 PLACES
EC NO:
118863
DRWN:
JRUTTER
CHK'D:
APPR:
KDEKOSKI
±
±
±
±
±
MINI50 SEALED 1X4 RCPT ASSY
0
0
0
0
0
2 PLACES
1 PLACE
0 PLACES
0.1
0.2
APPR BY
DATE
A
KDEKOSKI
DRAWING SIZE
2016/05/19
PRODUCT CUSTOMER DRAWING
SERIES
MATERIAL NUMBER
CUSTOMER
A
THIRD ANGLE PROJECTION
FORMAT: tb-prod-A1
REVISION: G
DATE: 2015/12/14
RELEASE STATUS
18
P1
RELEASE DATE
17
10.07.2017
16
12:48:24
15
14
13
12
11
10
9
8
7
C
=
E
6
REV
DRAFT WHERE APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
34967
SEE CHART
DOC TYPE
DOC PART
SHEET NUMBER
A1
4
DOCUMENT NUMBER
349674000
3
2
PSD
000
1 OF 3
1
5
