PANEL DISPLAY UNITS
160
×
160 mm
φ
8 mm 16
×
16 Dots
■
Outline Drawing
LNP128011
■
Absolute Maximum Ratings (Ta
=
25°C)
Item
Supply Voltage for Logic
Supply Voltage for LED
Input Voltage
Operating Ambient Temperature
Storage Temperature
■
Main Specifications (Ta
=
25°C)
Item
Display Colors
Dot Diameter
Dots Pitch
Dot Total Number
Display Surface Size
Brightness
(when lighting all lamps)
Operating Method
Clock Frequency
for Logic
Supply Voltage
Supply Current
Supply Voltage
for LED
Supply Current
Viewing Angle (50 % Luminouse)
Weight
358
CLK
V
CC
I
CC
V
LED
I
LED
2θ 1/2
B
Symbol
Ratings
Red, Green, Amber
φ
7.5 oval
9.9
256 (16
×
16)
160
×
160
R e d : 1,400
Green : 800 Controllable
1/4(Duty)
Dynamic lighting
Max 10
5.0
±
0.25
Max 0.15
5.0
±
0.2
Max 8.5 when two colors are
all turned “ON”
Min 60
700
mm
cd/m
2
mm
mm
Unit
Symbol
V
CC
V
LED
Vin
Topr
Tstg
Ratings
−
0.3
∼ +
5.5
Max 5.2
−
0.3
∼
V
CC
+
0.3
−
20
∼ +
45
−
30
∼ +
85
Unit
V
V
V
°C
°C
MHz
V
mA
V
A
°
g
