AMPMODU Interconnection System
Mod IV Wire-Applied Housings, Double-Row,
.100 x .100 [2.54 x 2.54] Centerline
(Continued)
Polarized
Strain Relief Locators
(on Housings 20 Positions
and Larger)
.175
[4.45]
Material
Black thermoplastic, flame retardant
A
±.003
B
[±0.08]
.100
[2.54]
Typ.
C ±.003
[±0.08]
.100
[2.54]
X
Typ.
.050
[1.27]
Typ.
.070
Typ.
[1.78]
Related Product Data
Contacts
— pages 211-213
Mateable Headers and Posts—
pages 117-131
.600
[15.24]
R
Optional
.240
[6.10]
Technical Documents
—
pages 277, 278
Product Specification
108-25007, 108-25019, 108-25020,
108-25021
Application Specification
114-25003, 114-25016
No. of
Pos.
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
48
50
52
54
56
58
60
64
66
70
72
Dimensions
B
.100
[2.54]
.200
[5.08]
.200
[5.08]
.300
[7.62]
.300
[7.62]
.400
[10.16]
.400
[10.16]
.500
[12.70]
.500
[12.70]
.600
[15.24]
.600
[15.24]
.700
[17.78]
.700
[17.78]
.800
[20.32]
.800
[20.32]
.900
[22.86]
.900
[22.86]
1.000
[25.40]
1.000
[25.40]
1.100
[27.94]
1.200
[30.48]
1.200
[30.48]
1.300
[33.02]
1.300
[33.02]
1.400
[35.56]
1.400
[35.56]
1.500
[38.10]
1.600
[40.64]
1.600
[40.64]
1.700
[43.18]
1.800
[45.72]
X
.100
[2.54]
Mod IV Wire-Applied Housings
Section X-X
Part Nos.
Unstamped**
2-87977-8
2-87977-9
3-87977-0
3-87977-1
3-87977-2
3-87977-3
3-87977-4
3-87977-5
3-87977-6
3-87977-7
3-87977-8
3-87977-9
4-87977-0
4-87977-1
4-87977-2
4-87977-3
4-87977-4
4-87977-5
4-87977-6
4-87977-7
5-87977-6
4-87977-8
4-87977-9
5-87977-0
5-87977-8
6-87977-0
5-87977-1
6-87977-2
5-87977-2
5-87977-3
5-87977-4
Keying Plugs
Part No. 86286-1
(Plugs into standard or intermediate
pressure receptacle contact)
Material
— Natural color nylon
A
.300
[7.62]
.400
[10.16]
.500
[12.70]
.600
[15.24]
.700
[17.78]
.800
[20.32]
.900
[22.86]
1.000
[25.40]
1.100
[27.94]
1.200
[30.48]
1.300
[33.02]
1.400
[35.56]
1.500
[38.10]
1.600
[40.64]
1.700
[43.18]
1.800
[45.72]
1.900
[48.26]
2.000
[50.80]
2.100
[53.34]
2.200
[55.88]
2.400
[60.96]
2.500
[63.50]
2.600
[66.04]
2.700
[68.58]
2.800
[71.12]
2.900
[73.66]
3.000
[76.20]
3.200
[81.28]
3.300
[83.82]
3.500
[88.90]
3.600
[91.44]
C
.100
[2.54]
.100
[2.54]
.200
[5.08]
.200
[5.08]
.300
[7.62]
.300
[7.62]
.400
[10.16]
.400
[10.16]
.500
[12.70]
.500
[12.70]
.600
[15.24]
.600
[15.24]
.700
[17.78]
.700
[17.78]
.800
[20.32]
.800
[20.32]
.900
[22.86]
.900
[22.86]
1.000
[25.40]
1.000
[25.40]
1.100
[27.94]
1.200
[30.48]
1.200
[30.48]
1.300
[33.02]
1.300
[33.02]
1.400
[35.56]
1.400
[35.56]
1.500
[38.10]
1.600
[40.64]
1.700
[43.18]
1.700
[43.18]
Stamped*
87977-1
87977-2
87977-3
87977-4
87977-5
87977-6
—
87977-8
—
1-87977-0
1-87977-1
—
—
—
—
—
—
1-87977-8
—
—
—
2-87977-1
—
—
—
—
2-87977-4
—
—
—
—
5
Part No. 87077-2
(Plugs directly into housing)
**Cavity
identification, part number and date code stamped on housing where size permits.
**No marking on housing or strain relief.
Notes:
1. Strain reliefs are available and may be purchased separately. Consult Tyco Electronics.
Notes:
2. Contact
Extraction/Lance Reset Tool No. 843996-3.
Note:
All part numbers are RoHS compliant.
217
Catalog 1307819
Revised 8-08
www.tycoelectronics.com
Dimensions are in inches and
millimeters unless otherwise
specified. Values in brackets
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA: 1-800-522-6752
Canada: 1-905-470-4425
Mexico: 01-800-733-8926
C. America: 52-55-1106-0803
South America: 55-11-2103-6000
Hong Kong: 852-2735-1628
Japan: 81-44-844-8013
UK: 44-8706-080-208
