Miniature Audio Epoxy Potted
106 Series
PC Board Mount
Features
Output power models from 5 to 1,500 milliwatt level available.
P.C. board mount - square pin type (0.025" square typical) - see mechanical information
below for lengths.
Bifilar winding technique used on center tapped units for balanced resistive and
capacitive characteristics.
Rugged black epoxy potted construction produces a completely sealed unit withstanding
severe environmental conditions including those of MIL-T-27 (Grade 5, Class S).
For the more economical open type P.C. mount types please refer to the
148
and
149
series.
Peak working voltage rating of: 200V
Referring to figures 1-9, if connection is not used - no pin will exist.
Nominal Impedance
Typical
Part No.
106C
106E
106EE
106G
106H
106J
106M
106Q
106R
106S
106T
106V
106W
106X
Applicaton
Input
Input
Input
Interstage
Interstage
Interstage
Interstage
Output
Output
Output
Output
Output
Output
Output
50000
600 ct
600 ct
4000
4000
10000
20000
48 ct
48 ct
100 ct
100 ct
250 ct
500 ct
500 ct
(Ohms)
Primary
Secondary
1,500 ct
600
600 ct
600 ct
2,600 ct
2,000 ct
2,000 ct
3.2
8
3.2
8
8
3.2
8
Max. Primary
D.C. ma.
(*1)
0
9
9
10
10
6.5
4.5
32
32
22
22
14
10
10
D.C. Resistance
(Ohms) +/- 15%
Primary
2400
65
65
340
340
700
1180
2.4
2.4
4.4
4.4
11
26
26
Secondary
52
83
83
24
100
89
89
0.3
0.7
0.3
0.7
0.7
0.3
0.7
Output
Milliwatts
(*2)
10
500
500
150
150
150
150
1500
1500
1500
1500
1500
1500
1500
Insertion
Loss
db (*3)
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Low Frequency
Roll Off
-1 db (Hz.) (*4)
60
150
150
215
215
215
215
170
170
170
170
170
170
170
Drawing
Figure
7
8
9
7
7
7
7
8
8
8
8
8
8
8
Data subject to change without notice
