AP2012SYCK Overview

SINGLE COLOR LED, SUPER BRIGHT YELLOW, 1.3 mm

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Kingbright
package instruction	2 X 1.25 MM, 1.10 MM HEIGHT, ROHS COMPLIANT, SMD, 2 PIN
Reach Compliance Code	compli
ECCN code	EAR99
color	SUPER BRIGHT YELLOW
color@wavelength	Yellow
Configuration	SINGLE
Maximum forward current	0.03 A
Maximum forward voltage	2.5 V
Lens type	WATER CLEAR
Nominal luminous intensity	120.0 mcd
Installation features	SURFACE MOUNT
Number of functions	1
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	SINGLE COLOR LED
total height	1.1 mm
method of packing	TAPE AND REEL
peak wavelength	590 nm
Maximum reverse voltage	5 V
shape	RECTANGULAR
size	1.3 mm
surface mount	YES
Terminal pitch	2.35 mm
perspective	120 deg

2.0x1.25mm SMD CHIP LED LAMP

AP2012SYCK

SUPER BRIGHT YELLOW

Features

2.0mmx1.25mm SMT LED,1.1mm THICKNESS.

LOW POWER CONSUMPTION.

WIDE VIEWING ANGLE.

IDEAL FOR BACKLIGHT AND INDICATOR.

VARIOUS COLORS AND LENS TYPES AVAILABLE.

PACKAGE : 2000PCS / REEL.

RoHS COMPLIANT.

Description

The Super Bright Yellow source color devices are made

with DH InGaAlP on GaAs substrate Light Emitting Diode.

Package Dimensions

Notes:

1. All dimensions are in millimeters (inches).

2. Tolerance is

±0.1(0.004")

unless otherwise noted.

3. Specifications are subject to change without notice.

SPEC NO: DSAD0940

APPROVED: J. Lu

REV NO: V.5

CHECKED: Allen Liu

DATE: MAR/18/2005

DRAWN: Y.W.WANG

PAGE: 1 OF 4

ERP: 1203000196
