APX1690
9-Set Over Voltage Protector
Features
•
9-Set Voltage Monitors (4 Fixed Inputs for 7.0V,
4.5V, 4.0V and 3.0V, 5 Adjustable Inputs with 1.
5V Internal Reference)
•
•
•
•
•
•
Input Voltage Range of 2~5V (Good for RTC
Battery)
Complementary Output to Drive 2N7002
Outputs with Latch
Quiescent Supply Current : 40µA
Quiescent Supply Current : 30µA When Output
Latch
V
REF
=1.5V±2.0% Over Temp
General Description
The APX1690 is a precise 9-Set over voltage protector.
The trigger voltages of IN1 to IN4 are internally set to
detect the 7.0V, 4.5V, 4.0V and 3.0V, respectively.
The trigger voltage of IN5 to IN9 can be set by using
external resistor divider with the internal reference
voltage (1.5V). The APX1690 offers 2% voltage set-
ting accuracy over temp, and an ultra low ground
current 40µA(max). The ground current is reduced
to 30µA(max) when an over voltage happened and
output is latched. Both complementary outputs (OUT
and OUT) are latched when an over voltage is de-
tected in either input. An external active high on re-
set pin can be used to reset the latch. A compact
package QSOP-16 is available for space saving
purpose.
Applications
•
•
Note Book Computer
Multiple Supply System
Pin Configuration
IN 1(7.0V )
IN 2(4.5V )
IN 3(4.0V )
IN 4(3.0V )
IN 5
IN 6
IN 7
NC
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
V
CC
GND
OUT
OUT
R eset
IN 9
IN 8
NC
APX1690 (QSOP -16)
ANPEC reserves the right to make changes to improve reliability or manufacturability without notice, and advise
customers to obtain the latest version of relevant information to verify before placing orders.
Copyright
ANPEC Electronics Corp.
Rev. A.3 - Dec., 2002
1
www.anpec.com.tw
°
APX1690
Ordering and Marking Information
APX1690
H a n d lin g C o d e
Tem p. R ange
P ackage C ode
P ackage C ode
M : Q SO P - 16
Tem p. R ange
E : - 2 0 to 7 0
°
C
H a n d lin g C o d e
TU : Tube
TR : Tape & R eel
A P X 1690 N :
A P X 1690
XXXXX
X X X X X - D a te C o d e
Pin Description
PIN
Name
IN1
IN2
IN3
IN4
IN5
IN6
IN7
NC
IN8
IN9
Reset
OUT
OUT
GND
V
CC
I/O
I
I
I
I
I
I
I
I
I
I
O
O
O
I
Description
Input pin for 7.0V detection
Input pin for 4.5V detection
Input pin for 4.0V detection
Input pin for 3.0V detection
Input pin for 1.5V detection
Input pin for 1.5V detection
Input pin for 1.5V detection
Input pin for 1.5V detection
Input pin for 1.5V detection
Input pin of reset signal (active high)
Output low signal when latched
Output high signal when latched
Ground pin for signal and power ground
Input pin of supply voltage
No.
1
2
3
4
5
6
7
8,9
10
11
12
13
14
15
16
Copyright
ANPEC Electronics Corp.
Rev. A.3 - Dec., 2002
2
www.anpec.com.tw
APX1690
Absolute Maximum Ratings
Symbol
Parameter
V
CC
Input Voltage
IN1~IN9, Reset All Input Pins
T
J
Operating Junction Temperature
T
STG
Storage Temperature
T
S
ESD
Soldering Temperature (10 seconds)
ESD Classification
Rating
7
7
-20 to 150
-65 to +150
260
2
Unit
V
V
°C
°C
°C
kV
Electrical Characteristics
T
A
=25°C, V
CC
=3V unless otherwise specified.
Symbol
V
CC
I
CC
V
REF
t
I
DRIVE
I
SINK
I
LATCH
V
T1
V
T2
V
T3
V
T4
V
T5
V
T6
V
T7
V
T8
V
T9
Reset
Parameter
Test Conditions
APX1690
Min.
Typ.
Max.
2
5
40
1.477 1.500 1.523
100
5
5
30
7±2%
4.5±2%
4±2%
3±2%
V
REF
V
REF
V
REF
V
REF
V
REF
0.5*V
CC
Unit
V
µA
V
µS
mA
mA
µA
V
V
V
Supply Voltage
Supply Current
Internal Reference Voltage
0~125°C
Debounce Time
Output Drive Current
C
OUT
=1nF
Output Sink Current
C
OUT
=1nF
Supply Current when Latch
Tripped Voltage of IN1
Tripped Voltage of IN2
Tripped Voltage of IN3
Tripped Voltage of IN4
Tripped Voltage of IN5
Tripped Voltage of IN6
Tripped Voltage of IN7
Tripped Voltage of IN8
Tripped Voltage of IN9
Reset Input Signal (Active High)
Copyright
ANPEC Electronics Corp.
Rev. A.3 - Dec., 2002
4
www.anpec.com.tw
