1MSWT-9: DescriptionPower/Signal Relay, SPDT, Momentary, 0.017A (Coil), 9VDC (Coil), 126mW (Coil), 1A (Contact), 28VDC (Contact), DC Input, AC/DC Output, Panel Mount,; CategoryMechanical and electronic products relay; File Size228KB，2 Pages; ManufacturerHi-G Relays

Download Datasheet Parametric View All

1MSWT-9 Overview

Power/Signal Relay, SPDT, Momentary, 0.017A (Coil), 9VDC (Coil), 126mW (Coil), 1A (Contact), 28VDC (Contact), DC Input, AC/DC Output, Panel Mount,

1MSWT-9 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
body height	9.53 mm
Body length or diameter	9.4 mm
Maximum coil current (DC)	0.017 A
Coil operating voltage (DC)	5.4 V
Coil power	126 mW
Coil release voltage (DC)	0.54 V
Coil resistance	630 Ω
Maximum coil voltage (DC)	9 V
Coil/Input Power Type	DC
Contact (AC) maximum rated R load	.25A@115VAC
Maximum contact current (AC)	0.25 A
Maximum contact current (DC)	1 A
Contact (DC) maximum rated R load	1A@28VDC
Maximum contact voltage (AC)	115 V
Maximum contact voltage (DC)	28 V
Contact/Output Power Type	AC/DC
Electrical life	100000 Cycle(s)
Installation features	PANEL MOUNT
operating hours	5 ms
Maximum operating temperature	125 °C
Minimum operating temperature	-65 °C
Relay action	MOMENTARY
Relay function	SPDT
Relay type	POWER/SIGNAL RELAY
release time	9 ms
seal	HERMETICALLY SEALED
surface mount	NO
Termination type	WIRE
Base Number Matches	1
