1MAPD-26 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Mechanical and electronic products> relay> 1MAPD-26

1MAPD-26: DescriptionPower/Signal Relay, SPDT, Momentary, 0.013A (Coil), 26VDC (Coil), 338mW (Coil), 1A (Contact), 28VDC (Contact), DC Input, AC/DC Output, Through Hole-Straight Mount,; CategoryMechanical and electronic products relay; File Size138KB，2 Pages; ManufacturerHi-G Relays

Download Datasheet Parametric View All

1MAPD-26 Overview

Power/Signal Relay, SPDT, Momentary, 0.013A (Coil), 26VDC (Coil), 338mW (Coil), 1A (Contact), 28VDC (Contact), DC Input, AC/DC Output, Through Hole-Straight Mount,

1MAPD-26 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
body height	7.11 mm
Body length or diameter	9.4 mm
Maximum coil current (DC)	0.013 A
Coil operating voltage (DC)	14.2 V
Coil power	338 mW
Coil release voltage (DC)	1.25 V
Coil resistance	2000 Ω
Maximum coil voltage (DC)	26 V
Coil/Input Power Type	DC
Contact (AC) maximum rated R load	.25A@115VAC
Maximum contact current (AC)	0.25 A
Maximum contact current (DC)	1 A
Contact (DC) maximum rated R load	1A@28VDC
Maximum contact voltage (AC)	115 V
Maximum contact voltage (DC)	28 V
Contact/Output Power Type	AC/DC
Electrical life	100000 Cycle(s)
Installation features	THROUGH HOLE-STRAIGHT MOUNT
operating hours	3.5 ms
Maximum operating temperature	125 °C
Minimum operating temperature	-65 °C
Relay action	MOMENTARY
Relay function	SPDT
Relay type	POWER/SIGNAL RELAY
release time	5.5 ms
seal	HERMETICALLY SEALED
surface mount	NO
Termination type	SOLDER
Base Number Matches	1
