LM1MA142WKT1G datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> LM1MA142WKT1G

LM1MA142WKT1G: DescriptionRECTIFIER DIODES,COMMON CATHODE,80V V(RRM),SOT-323; CategoryDiscrete semiconductor diode; File Size96KB，4 Pages; ManufacturerLRC; Websitehttp://www.lrc.cn; Environmental Compliance

Download Datasheet Parametric Compare View All

LM1MA142WKT1G Overview

RECTIFIER DIODES,COMMON CATHODE,80V V(RRM),SOT-323

LM1MA142WKT1G Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	LRC
package instruction	R-PDSO-G3
Reach Compliance Code	unknow
ECCN code	EAR99
Configuration	COMMON CATHODE, 2 ELEMENTS
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.2 V
JESD-30 code	R-PDSO-G3
Maximum non-repetitive peak forward current	0.75 A
Number of components	2
Number of terminals	3
Maximum operating temperature	150 °C
Maximum output current	0.1 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum power dissipation	0.15 W
Maximum repetitive peak reverse voltage	80 V
Maximum reverse recovery time	0.003 µs
surface mount	YES
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

LESHAN RADIO COMPANY, LTD.

Common Cathode Silicon

Dual Switching Diode

This Common Cathode Silicon Epitaxial Planar Dual Diode is designed for

use in ultra high speed switching applications. This device is housed in the

SC-70 package which is designed for low power surface mount applications.

• Fast t

, < 3.0 ns

• Low C

, < 2.0 pF

• Pb-Free package is available

• Available in 8 mm Tape and Reel

Use LM1MA141/2WKT1 to order the 7 inch/3000 unit reel.

Use LM1MA141/2WKT3 to order the 13 inch/10,000 unit reel.

LM1MA141WKT1

LM1MA142WKT1

SC–70/SOT–323 PACKAGE

COMMON CATHODE

DUAL SWITCHING DIODE

40/80 V–100 mA

SURFACE MOUNT

CASE 419–04, STYLE 5

MAXIMUM RATINGS

= 25°C)

Rating

Symbol

Reverse Voltage

LM1MA141WKT1

LM1MA142WKT1

Peak Reverse Voltage

LM1MA141WKT1

Forward Current

Peak Forward Current

Peak Forward Surge Current

LM1MA142WKT1

Single

Dual

Single

Dual

Single

Dual

FSM(1)

SOT–323 /SC – 70

Value

100

150

225

340

500

750

Unit

CATHODE

ANODE

mAdc

Marking Symbol

Type No.141WK142WK

Symbol

THERMAL CHARACTERISTICS

Rating

Power Dissipation

Junction Temperature

Storage Temperature

Symbol

stg

Max

150

–55 ~ +150

Unit

°C

The “X” represents a smaller alpha digit Date

Code. The Date Code indicates the actual month

in which the part was manufactured.

ELECTRICAL CHARACTERISTICS

= 25°C)

Characteristic

Symbol

Reverse Voltage Leakage Current LM1MA141WKT1

LM1MA142WKT1

Forward Voltage

Reverse Breakdown Voltage

Diode Capacitance

Reverse Recovery

1. t = 1 SEC

2. t

Test Circuit

LM1MA141WKT1

LM1MA142WKT1

Time

rr(2)

Condition

= 35 V

= 75 V

= 100 mA

= 100

µA

=0, f=1.0 MHz

=10mA,V

=6.0V

=100Ω,I

=0.1 I

Min

—

Max

0.1

1.2

—

2.0

3.0

Unit

µAdc

Vdc

LM1MA141/2WKT1-1/4

LM1MA142WKT1G Related Products

	LM1MA142WKT1G	LM1MA141WKT1	LM1MA141WKT1G	LM1MA141WKT3	LM1MA142WKT1	LM1MA141WKT3G
Description	RECTIFIER DIODES,COMMON CATHODE,80V V(RRM),SOT-323	RECTIFIER DIODES,COMMON CATHODE,80V V(RRM),SOT-323	RECTIFIER DIODES,COMMON CATHODE,80V V(RRM),SOT-323	RECTIFIER DIODES,COMMON CATHODE,80V V(RRM),SOT-323	RECTIFIER DIODES,COMMON CATHODE,80V V(RRM),SOT-323	RECTIFIER DIODES,COMMON CATHODE,80V V(RRM),SOT-323
Diode type	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	SIGNAL DIODE	RECTIFIER DIODE
Maker	LRC	LRC	LRC	LRC	-	LRC
Reach Compliance Code	unknow	unknow	unknow	unknow	-	unknow
ECCN code	EAR99	EAR99	EAR99	EAR99	-	EAR99
Maximum forward voltage (VF)	1.2 V	1.2 V	1.2 V	1.2 V	-	1.2 V
Maximum non-repetitive peak forward current	0.75 A	0.75 A	0.75 A	0.75 A	-	0.75 A
Maximum operating temperature	150 °C	150 °C	150 °C	150 °C	-	150 °C
Maximum output current	0.1 A	0.15 A	0.1 A	0.15 A	-	0.1 A
Maximum repetitive peak reverse voltage	80 V	40 V	40 V	40 V	-	40 V
Maximum reverse recovery time	0.003 µs	0.003 µs	0.003 µs	0.003 µs	-	0.003 µs
surface mount	YES	YES	YES	YES	-	YES
