SAW Components
SAW RF filter
Data sheet
Application
s
Low-loss RF filter for remote control receivers
s
No matching network required for operation at 50
Ω
B4301
915.00 MHz
Package size 1.4 x 1.1 x 0.4
Package code QCS5P
RoHS compatible
Approximate weight 0.003 g
Package for
Surface Mount Technology
(SMT)
s
Ni, gold-plated terminals
s
AEC-Q200 qualified component family (operable
temperature range –40˚C to +85˚C)
s
Electrostatic Sensitive Device
(ESD)
s
s
s
s
s
mm
3
0.325
2 3
1
0.575
Features
0.25
bottom view
5
0.5 0.5
0.4
4
side view
1.4
1.1
top view
Pin configuration
s
1
s
4
s
2,3,5
Input
Output
to be grounded
Please read
cautions and warnings and
important notes
at the end of this document.
2
December 01, 2010
SAW Components
SAW RF filter
Data sheet
Characteristics
Temperature range for specification:
Terminating source impedance:
Terminating load impedance:
T = –40 ˚C to +85 ˚C
Z
S
=
50
Ω
Z
L
=
50
Ω
min.
Center frequency
f
C
—
typ.
@ 25 ˚C
915.00
max.
—
B4301
915.00 MHz
MHz
Maximum insertion attenuation
α
max
902.00 ... 928.00 MHz
Amplitude ripple
(p-p)
∆α
902.00 ... 928.00 MHz
Attenuation
10.00
800.00
845.00
947.00
970.00
1020.00
...
...
...
...
...
...
800.00
845.00
880.00
970.00
1020.00
1200.00
MHz
MHz
MHz
MHz
MHz
MHz
α
—
1.5
2.5
dB
—
0.9
1.8
dB
42
40
35
13
33
35
50
46
43
22
39
41
—
—
—
—
—
—
dB
dB
dB
dB
dB
dB
Maximum ratings
Operable temperature range T
Storage temperature range T
stg
DC voltage
V
DC
Source power
P
S
–40/+85
–40/+85
0
10
˚C
˚C
V
dBm
source impedance 50
Ω
Please read
cautions and warnings and
important notes
at the end of this document.
