Ceramic
Low Pass Filter
DC to 5400 MHz
Maximum Ratings
Operating Temperature
Storage Temperature
-55°C to 100°C
-55°C to 125°C
EW!
N
LFTC-5400
Features
• miniature size, 0.15"X0.15"X.028"
• low profile, .028" height
• high power handling, 19W
Applications
Pin Connections
RF IN
RF OUT
GROUND
** RF IN & RF OUT can be interchanged
MODEL
NO.
2**
5**
1,3,4,6
CASE STYLE: FR933
PRICE: $3.75 ea. QTY (10-49)
• harmonic rejection
• internal rejection
• receivers & transmitters
Low Pass Filter Electrical Specifications (T
AMB
=25°C)
PASSBAND
(MHz)
(loss < 1 dB)
Typ.
LFTC-5400
DC-5400
Outline Drawing
fco, MHz
Nom.
(loss 3 dB)
Typ.
6410
STOP BAND (MHz)
( > 20 dB) ( loss> 40 dB)
9000-11000
—
fr20dB
Typ.
12000
VSWR (:1)
Passband
Typ.
1.1
POWER
INPUT*
(W)
19
LF5
* Derate linearly to 8W at 100°C ambient
typical frequency response
ATTENUATION
schematic
RF IN
RF OUT
40dB
20dB
3dB
f co
f
R 20dB
Typical Performance Data at 25°C
Frequency
(MHz)
Insertion Loss
(dB)
0.07
0.21
0.88
2.69
8.27
24.11
30.45
29.61
30.32
19.81
LFTC-5400
VSWR
100
VSWR
(:1)
1.02
1.02
1.18
2.76
8.99
21.73
20.45
22.87
19.76
11.03
Outline Dimensions (
inch
)
mm
A
.150
3.81
H
—
—
B
.150
3.81
J
.060
1.52
C
.028
0.71
K
.030
0.76
D
—
—
L
.184
4.67
E
—
—
M
.050
1.27
F
.035
0.89
N
.075
1.91
G
.028
0.71
P
wt.
.044 grams
1.12
0.15
100.00
1000.00
5400.00
6410.00
7000.00
8200.00
Demo Board MCL P/N: TB-233
Suggested PCB Layout (PL-112)
11000.00
12000.00
13000.00
15000.00
LFTC-5400
INSERTION LOSS
40
35
INSERTION LOSS (dB)
30
25
20
15
10
5
0
0
3000
6000
9000
12000
VSWR
10
15000
1
0
3000
6000
9000
12000
15000
FREQUENCY (MHz)
FREQUENCY (GHz)
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
ISO 9001 CERTIFIED
NO. OF
SECTIONS
7
REV. J
M88950
LFTC-5400
EDB-020540
AD/YB/CP
030918
