The DA7212 is an ultra-low power audio codec targeting portable audio devices. The input paths
support stereo FM line input and up to four analogue (or two analogue and two digital) microphones
with two independent microphone biases. Comprehensive analogue mixing and bypass paths to the
output drivers are available.
The headphone output is true-ground Class G with integrated charge pump. There is also a
differential Class AB speaker driver that can serve as a mono lineout.
Digital audio transfer to/from the external processor is via a bi-directional digital audio interface that
supports all common sample rates and formats. The device may be operated in slave or master
modes using the internal PLL which may be bypassed if not required.
To fully optimise each customer application, a range of built in filtering, equalisation and audio
enhancements are available. These are accessible by the processor over the I2C serial interface.
Key features
■
100 dB SNR stereo audio playback into 16 Ω
■
Built-in 5-band equaliser, ALC and noise-gate
headphones
functions
Built-in beep generator
Integrated system controller to eliminate pops
and clicks
Minimised external component count
34-ball WL-CSP (4.54 mm x 1.66 mm)
package
Staggered 0.5 mm pitch for easy PCB routing
allowing low cost manufacture
■
3.1 mW power consumption for stereo DAC to
■
headphone playback
■
■
1.2 W mono speaker driver
■
650 µW mono voice record
■
■
Stereo digital microphone support
■
■
Supports up to four analogue microphones
■
■
Two low-noise microphone-bias outputs
■
Low-power PLL provides system clocking and
audio sample rate flexibility
Applications
■
Personal Media Players
■
Audio headphone/headsets
■
Wearables
■
Embedded applications
■
Arduino compatible development systems
Figure 1: The DA7212 chip
Datasheet
Revision 3c
1 of 129
24-Nov-2015
© 2015 Dialog Semiconductor
