LDA211 is a dual optocoupler with a single or darlington
transistor output. A bi-directional or uni-directional input is
available depending on which model you choose. Current
transfer ratios range from 33% to 1000%
Features
•
AC and DC Input Versions Available
•
Small 8 Pin DIP Package
•
100mA Continuous Load Rating
•
3750V
RMS
Input/Output Isolation
•
Machine Insertable, Wave Solderable
•
Surface Mount and Tape & Reel Versions Available
Applications
•
Telecom Switching
•
Tip/Ring Circuits
•
Modem Switching (Laptop, Notebook, Pocket Size)
•
Loop Detect
•
Ring Detect
•
Current Sensing
Approvals
•
UL Recognized: File Number E76270
•
CSA Certified: File Number LR 43639-10
•
BSI Certified:
•
BS EN 60950:1992 (BS7002:1992)
Certificate #:7344
•
BS EN 41003:1993
Certificate #:7344
Ordering Information
Part #
LDA211
LDA211S
LDA211STR
Description
8 Pin DIP (50/Tube)
8 Pin Surface Mount (50/Tube)
8 Pin Surface Mount (1000/Reel)
Pin Configuration
LDA211 Pinout
1
2
3
4
8
7
6
5
DS-LDA211-R1
www.clare.com
1
LDA211
Absolute Maximum Ratings (@ 25
o
C)
Parameter
Input Power Dissipation
Input Control Current
Peak (10ms)
Reverse Input Voltage
Phototransistor
Power Dissipation
Total Package Dissipation
Isolation Voltage
Input to Output
Operational Temperature
Storage Temperature
Soldering Temperature
DIP Package
Surface Mount Package
(10 Seconds Max.)
1
2
3
Min
-
-
-
-
-
-
3750
-40
-40
-
-
Typ Max Units
-
-
-
-
-
-
-
-
-
-
-
150
1
100
1
5
150
2
800
3
mW
mA
A
V
mW
mW
Absolute Maximum Ratings are stress ratings. Functional
operation of the device at these or any other conditions
beyond those indicated in the operational sections of this
data sheet is not implied. Exposure of the device to the
absolute maximum ratings for an extended period may
degrade the device and effect its reliability.
-
V
RMS
°
C
+85
+125
°
C
+260
+220
°
C
°
C
Derate Linearly 1.33 mw/
o
C
Derate Linearly 2.0 mw/
o
C
Derate Linearly 6.67 mw/
o
C
Electrical Characteristics
PARAMETER
Output Characteristics @ 25°C
Phototransistor Blocking Voltage
Phototransistor Output Current
Saturation Voltage
I
C
=.15mA, I
F
=.05mA
Current Transfer Ratio
Output Capacitance
Capacitance Input to Output
Input Characteristics @ 25°C
Input Control Current
Input Voltage Drop
Input Reverse Voltage
(LDA201, LDA211)
Input Reverse Current
(LDA201, LDA211)
Common Characteristics @ 25°C
Input to Output Isolation
CONDITIONS
I
C
=10µA
V
CE
=5V, I
F
=0mA
I
C
=2mA, I
F
=16mA
V
SAT
I
F
=6mA, V
CE
=0.5V
50V, f=1 MHz
-
I
C
=2mA, V
CE
=0.5V
I
F
=5mA
-
V
R
=5V
SYMBOL
BV
CEO
I
CEO
V
SAT
-
CTR
C
OUT
MIN
20
-
-
-
300
-
TYP
50
100
-
0.5
1000
3
3
2
1.2
-
-
MAX
-
500
0.5
-
-
-
-
100
1.4
5
10
UNITS
V
nA
V
V
%
pF
pF
mA
V
V
nA
I
F
V
F
V
R
I
R
6
0.9
-
-
-
V
I/O
3750
-
-
V
RMS
2
www.clare.com
Rev. 1
LDA211
Performance Data
LDA210/LDA211
Typical Normalized CTR vs. Forward Current
(V
CE
= 0.8V)
2.5
Normalized CTR (%)
2.0
1.5
1.0
0.5
0
0
2
4
6
8
10
12
14
16
18
20
I
F
(mA)
Normalized CTR (%)
LDA210/LDA211
Typical Normalized CTR vs. Temperature
(V
CE
= 0.8V)
3.0
2.5
2.0
1.5
1.0
0.5
0
-40
-20
0
20
40
60
80
100
Temperature (°C)
2mA
I
C
(mA)
5mA
10mA
15mA
20mA
1mA
LDA210/LDA211
Typical Collector Current vs. Forward Current
(V
CE
= 0.8V)
16
14
12
10
8
6
4
2
0
0
2
4
6
8
10
12
14
16
18
20
I
F
(mA)
*The Performance data shown in the graphs above is typical of device performance. For guaranteed parameters not indicated in the written specifications, please contact
our application department.
Rev. 1
www.clare.com
3
LDA211
Performance Data
8 Pin DIP Surface Mount (“S” Suffix)
7.620
±
.254
(.300
±
.010)
4.445
±
.127
(.175
±
.005)
3.302
(.130)
.635 TYP.
(.025)
.254 TYP.
(.010)
6.350
±
.127
(.250
±
.005)
9.652
±
.381
(.380
±
.015)
2.540
±
.127
(.100
±
.005)
PC Board Pattern
(Top View)
2.540
±
.127
(.100
±
.005)
9.525
±
.254
(.375
±
.010)
8.305
±
.127
(.327
±
.005)
1.905
±
.127
(.075
±
.005)
1.498
±
.127
(.059
±
.005)
.457
±
.076
(.018
±
.003)
8.077
±
.127
(.318
±
.005)
Tape and Reel Packaging for 8 Pin Surface Mount Package
330.2 DIA.
(13.00)
Top Cover
Tape Thickness
.102 MAX.
(.004)
2.007
±
.102 1.498
±
.102 3.987
±
.102
(.079
±
.004) (.059
±
.004) (.157
±
.004)
6.731 MAX.
1.753
±
.102
(.265)
(.069
±
.004)
.406 MAX.
(.016)
7.493
±
.102
(.295
±
.004)
12.090
(.476)
4.877
(.192)
1
8
16.002
±
.305
(.630
±
.012)
10.300
(.405)
Embossed Carrier
Top Cover
Tape
.050R TYP.
11.989
±
.102
(.472
±
.004)
User Direction of Feed
10.300
±
.102
(.405
±
.004)
1.549
±
.102
(.061
±
.004)
Embossment
Dimensions
mm
(inches)
4
www.clare.com
Rev. 1
