www.eLED.com
Package Dimensions & Internal
Circuit Diagram
DIGIT NUMERIC DISPLAY
ESA56-11EWA
14.2mm (0.56INCH)
SINGLE
HIGH EFFICIENCY RED
Features
1.0.56 INCH DIGIT HEIGHT.
2.LOW CURRENT OPERATION.
3.EXCELLENT CHARACTER APPEARANCE.
4.UNIVERSAL
±1.OVERFLOW
AVAILABLE.
5.EASY MOUNTING ON P.C. BOARDS OR SOCKETS.
6.I.C. COMPATIBLE.
7.CATEGORIZED FOR LUMINOUS INTENSITY,
YELLOW AND GREEN CATEGORIZED FOR COLOR.
8.MECHANICALLY RUGGED.
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Specifications are subject to change without notice.
9.STANDARD : GRAY FACE, WHITE SEGMENT.
Description
The High Efficiency Red source color devices are made with Gallium Arsenide Phosphide on Gallium Phosphide Orange
Light Emitting Diode.
Selection Guide
P a r t No .
Em i t t i n g Co l o r
+M a t e r i a l
λ
D ( n m )
L ens T y p e
Min .
Iv ( u c d )
@ 10 m A
Typ .
De sc r i p t i o n
ESA56-11EWA
GaAsP/GaP
625
WHI TE DI FFUSED
1900
6400
Common Anode,
Rt. Hand Decimal
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
DATA NO :EA0358
REV NO :V1
DATE :OCT/13/2001
ESA56-11EWA-1/2
www.eLED.com
Electrical / Optical Characteristics at T
A
=25°C
°
Sy mbo l
λ
pe a k
λD
∆λ
1/2
C
V
F
I
R
P arameter
P e a k W a v e le n g th
Do m i n a t e W a v e l e n g t h
Spe ctra l L in e
Ha l fwi d t h
C a pa cita n ce
F o r wa r d V o l t a g e
R e v e r se C u r r e n t
De v i c e
Hi g h E ffi c i e n c y R e d
Hi g h E ffi c i e n c y R e d
Hi g h E ffi c i e n c y R e d
Hi g h E ffi c i e n c y R e d
Hi g h E ffi c i e n c y R e d
Hi g h E ffi c i e n c y R e d
Typ.
627
625
45
15
2 .0
2.5
Max .
Un i t s
nm
nm
nm
pF
V
uA
T e s t Co n d i t i o n s
I
F
=20mA
I
F
=20mA
I
F
=20mA
V
F
=0V;f=1MHz
I
F
=20mA
V
R
= 5V
Absolute Maximum Ratings at T
A
=25°C
°
P a ra me te r
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Solder Temperature [2]
Note:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 4mm below package base.
H i g h Ef f i c i e n c y R e d
105
30
160
5
-40° C To +85°C
260° C For 5 Seconds
Un i t s
mW
mA
mA
V
Highe Efficiency Red ESA56-11EWA
DATA NO :EA0358
REV NO :V1
DATE :OCT/13/2001
ESA56-11EWA-2/2
