Ordering number : EN*5783
LC9997M
1/5-Inch Frame Transfer CCD
NTSC Color Image Sensor
Preliminary
Overview
The LC9997M is a 1/5-inch optical size frame transfer
CCD solid-state image sensor.
Package Dimensions
unit: mm
3217
[LC9997M]
Features
• Effective pixels [total pixels]: 508
×
246 [532
×
250] (H
×
V)
• Number of optical black pixels:
Horizontal: 2 in front, 22 in back
Vertical: 2.5 above, 1.5 below
• Dummy bits: Horizontal: 4 pixels
• Horizontal resolution: 330 TV lines
• Small form factor supports compact application products
• 20-pin half-pitch transparent DIP package
• Horizontal shift register operates at 5 V.
• Supports variable-speed electronic shutter operation.
Device Structure
•
•
•
•
•
•
1/5-inch optical size frame transfer CCD image sensor
Unit cell size: 5.8 µm
×
9.0 µm (H
×
V)
Chip size: 4.18 mm
×
5.10 mm (H
×
V)
Parallel gate CCD sensor
Built-in high-sensitivity output amplifier
Cy-G-Ye-W mosaic complementary color filters
Specifications
Absolute Maximum Ratings
at Ta = 25°C
Parameter
Supply voltage
Load gate voltage
N substrate - p-well voltage
N substrate - image and storage area voltage
Symbol
V
DD
V
GG
V
PW
= 0 V
V
PW
= 0 V
NSUB–VPW
NSUB–
φ
1 to
φ
4,
φ
S1 to
φ
S4
Horizontal clock pin,
φ
R: V
PW
= 0 V
Pin voltage
Other clock pins: V
PW
= 0 V
Other pins: V
PW
= 0 V
Operating temperature
Storage temperature
Topr
Tstg
Conditions
Ratings
–0.3 to +18
–0.3 to +5
–0.3 to +50
–0.3 to +55
–0.3 to +18
–15 to +18
–0.3 to +10
–10 to +60
–30 to +80
Unit
V
V
V
V
V
V
V
°C
°C
SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquarters
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
53098RM (OT) No. 5783-1/11
LC9997M
Clock Voltage Conditions
at a frame shift frequency of 3.58 MHz
Parameter
Imaging area pulse signals: ø1, ø2, ø3, ø4
Pulse amplitude
Low level
Storage area pulse signals: øS1, øS2
Pulse amplitude
Low level
Storage area pulse signals: øS3, øS4
Pulse amplitude
Low level
Horizontal transfer pulse signals: øH1, øH2
Pulse amplitude
Low level
Reset gate: øR
Pulse amplitude
Low level
Substrate pulse: øNSUB
Pulse amplitude
Low level
V
HSUB
V
LSUB
*2.
See Figure 1.
See Figure 1.
30.0
17.5
18.0
40.0
18.5
V
V
V
PR
V
LR
4.5
4.2
5.0
4.5
5.5
4.8
V
V
V
PH
V
LH
4.5
0
5.0
0
5.5
0.5
V
V
V
PSL
V
LSL
14.0
–9.0
14.5
–8.5
15.0
–8.0
V
V
V
PSL
V
LSL
14.0
–8.0
14.5
–7.5
15.0
–7.0
V
V
V
PIF
V
LIF
*1
*1
14.0
–10.0
14.5
–9.5
15.0
–9.0
V
V
Symbol
Conditions
Ratings
min
typ
max
Unit
Notes: 1. Insert 47-pF capacitance as shown in Figure 2.
2. V
HSUB
must be adjusted so that the saturated output is maximum within the range where image degradation does not occur.
Shutter pulse
Slice pulse
Charge sweep-out pulse
Frame shift
Imaging area pulses
One field
Figure 1
Vertical driver IC
LC89901V
Core IC
LC99053
Figure 2
Bias Conditions
Parameter
P - well
Output circuit voltage
OG bias
Symbol
V
PW
V
DD
V
GG
V
OG
*3
*4
*4
14.5
1.2
4.5
Conditions
Ratings
min
typ
0
15.0
1.5
5.0
15.5
1.8
5.5
max
Unit
V
V
V
V
No. 5783-5/11
