LC87F66C8A datasheet, PDF - EEWORLD Datasheet

LC87F66C8A: Description8-Bit Single Chip Microcontroller with 64 KB FEPROM and 2048-Byte RAM On Chip　; CategoryThe embedded processor and controller Microcontrollers and processors; File Size756KB，23 Pages; ManufacturerSANYO; Websitehttp://www.semic.sanyo.co.jp/english/index-e.html

Download Datasheet Parametric View All

LC87F66C8A Overview

8-Bit Single Chip Microcontroller with 64 KB FEPROM and 2048-Byte RAM On Chip　

Parameter Name	Attribute value
Maker	SANYO
Parts packaging code	QFP
package instruction	QFP,
Contacts	100
Reach Compliance Code	unknow
Has ADC	YES
Address bus width
bit size	8
maximum clock frequency	20 MHz
DAC channel	NO
DMA channel	NO
External data bus width
JESD-30 code	R-PQFP-G100
length	20 mm
Number of I/O lines	70
Number of terminals	100
Maximum operating temperature	70 °C
Minimum operating temperature	-20 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	QFP
Package shape	RECTANGULAR
Package form	FLATPACK
Certification status	Not Qualified
ROM programmability	FLASH
Maximum seat height	3 mm
speed	20 MHz
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	QUAD
width	14 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER

"##

"$%! &'()

&(,#- !

. /

!0*

0)*

02()*

4! *

50')

! 0 !

50'

"$×

"6 "#1*

"#$%
