48CPS3-05-S datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> 48CPS3-05-S

48CPS3-05-S: DescriptionDC-DC Regulated Power Supply Module, 1 Output, 3W, Hybrid, PLASTIC PACKAGE-8; CategoryPower/power management The power supply circuit; File Size195KB，1 Pages; ManufacturerIBEK Electronic Ag

Download Datasheet Parametric View All

48CPS3-05-S Overview

DC-DC Regulated Power Supply Module, 1 Output, 3W, Hybrid, PLASTIC PACKAGE-8

48CPS3-05-S Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Parts packaging code	MODULE
package instruction	,
Contacts	8
Reach Compliance Code	compliant
ECCN code	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	75 V
Minimum input voltage	18 V
Nominal input voltage	48 V
JESD-30 code	R-PDMA-P8
length	32 mm
Number of functions	1
Output times	1
Number of terminals	8
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output voltage	5.1 V
Minimum output voltage	4.9 V
Nominal output voltage	5 V
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
surface mount	NO
technology	HYBRID
Temperature level	INDUSTRIAL
Terminal form	PIN/PEG
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	3 W
Fine-tuning/adjustable output	NO
width	20 mm
Base Number Matches	1

Preview

Download Datasheet

View All

IBEK

€

www.ibek.ch

Single & double outputs

Input to output isolated

•

3 Watt

DC-DC-Converter

Family CPL3 / CPS3

Ultra wide 1:4 input voltage ranges

Very high efficiency up to 83%

High reliability

Continuous no-load and short-circuit proof

CPS3: Extended ambient temperature range -40…+85‚C

DIL 24 case with industrial pinning

No derating

Made in Switzerland, accordingly ISO 9001:2000

2 years warranty

Electromagnetic emission EN 55022 < B

Conducted and radiated emissions

24 CPL

No load input current

Switching frequency

Output voltage accuracy

Static line regulation

Static load regulation FL to • L

Output voltage noise (20 MHz BW)

Efficiency

I/O Electric strength test voltage

Coupling capacitance

Ambient temperature range

Case temperature range

Storage temperature range

Case material

MTBF, GB @ 40ƒC case

(MIL-HDBK-217F, Notice 2)

Standard Types

Input voltage

VDC

Output

VDC

Single output

xx CPL3-05-T

RoHS

9…36

500

mA typ. xx CPL3-12-T

RoHS

(nominal 24)

250

130 kHz typ.

xx CPL3-15-T

RoHS

200

45 V for 10 ms

€ 2% max.

Double output

repetition rate 10 s

€ 15 mV typ.

xx CPL3-0505-T

RoHS

€ 5

€ 250

0…2%; 5 VDC outputs 0…5% typ.

xx CPL3-1212-T

RoHS

18…75

• 12

• 125

100 mVpp typ.

xx CPL3-1515-T

RoHS

(nominal 48)

€ 15

€ 100

79% to 83% typ.

Single output

1500 VDC

xx CPS3-05-S

RoHS

500

300 pF

xx CPS3-12-S

RoHS

250

CPL3

CPS3

xx CPS3-15-S

RoHS

200

-T: -25…+71ƒC;

-S: -40…+85ƒC

Double output

-T: -25…+95ƒC;

-S: -40…+105ƒC

xx CPS3-0505-S

RoHS

€ 5

€ 250

-T: -55…+105ƒC;

-S: -55…+105ƒC

xx CPS3-1212-S

RoHS

€ 12

€ 125

Non-conductive plastic, UL94 V-0 rated

xx CPS3-1515-S

RoHS

€ 15

€ 100



2.300.000 hours

To complete type number replace "xx" by the required nominal input

voltage, e.g. 24 CPL3-05-T

RoHS

Double outputs should have symmetrical load conditions to comply

with the specifications listed on the left side.

48 CPL

24 CPS

48 CPS

Modifications and customs are available upon request.

Dimensions in mm (inches)

Pin Configuration

Single output

-Gi

No Pin

+Vo

-Go

+Vi

Double output

-Gi

-Vo

+Vo

+Vi

Specifications subject to change without notice

15.12.2008

More power with IBEK

€

Page 7
