Pomona
®
Model 3786
Minigrabber® Test Clips To
Double Banana Plug
FEATURES:
41 x 36 T.C., PVC insulated, 2.21 (.087) O.D.
•
Converts double Banana Jacks to Minigrabber Test
Clip.
One Red Lead, one Black Lead
•
Lengths other than those specified are available
Conn: 2
nd
End-Minigrabber®
upon request.
Material: Contact – Beryllium Copper per
MATERIALS:
QQ-C-533, Alloy 165, ¼ HM.
st
Conn: 1 End-Double Banana Plug
Spring: stainless steel, Alloy 302.
Material: Spring-Beryllium Copper per
Finish: Contact – Gold plated per MIL-G-45204,
QQ-C-533, Alloy 172, Cond. HT.
Type I, Class 00.
Plug Body: Brass per QQ-B-626, Alloy 360,
Insulation: Glass filled Nylon. Color: One Red and
½ Hard.
one Black.
Finish: Nickel plated per QQ-N-290,
Marking: “POMONA ELECTRONICS
Class 2, 200/300 microinches.
“MINIGRABBER®”.
Insulation: Polypropylene molded to plug
RATINGS:
bodies and cable. Color matches color of
Operating Voltage: 300 VRMS/DC
cable.
Operating Temperature: +50°C. (+122°F.) Max
Marking: “POMONA ELECTRONICS CO.,
Current: 5 Amperes
INC. POMONA CALIFORNIA”.
ORDERING INFORMATION:
Model 3786-C-XX
Cable: RG58C/U.
XX=Cable Length, Standard Length: 18” (457), 24”
Marking: “POMONA 3786-C-XX”.
(610), 36” (914), 48” (1219), 60” (1524)
Molded Breakout: PVC molded to breakout leads
Ordering Example: Model 3786-C-60 indicates 60” in
and cable. Color: Black Breakout Leads: 20 AWG, length.
All dimensions are in inches. Tolerances (except noted): .xx = ±.02” (,51 mm), .xxx = ± .005” (,127 mm).
All specifications are to the latest revisions. Specifications are subject to change without notice.
Registered trademarks are the property of their respective companies. Made in USA
6/9/99
SY/EH/LS
Sales: 800-490-2361 Fax: 888-403-3360
Technical Assistance: 800-241-2060
PomonaACCESS
90584
(800) 444-6785 or (425) 446-6010
More drawings available at www.pomonaelectronics.com
Page 1 of 1
S:\Engineering \Release\DataSheets\FlukeDataSheet\d3786_1_01.doc
