Round Style
Analog Panel Meters
• UL Recognized - File # E91015
Except for the Wattmeters & Frequency Meters
• Glass Window for optimum viewing
• Rugged black plastic case
• Black spade-type pointer for easy distant reading
Ordering Information
Self-Shielding Movement
Model / Size and Catalog No.
Range
0 - 100
Approx.
Impedance (Ohms)
3400
3 - 1/2”
Model 45
04080
AC Milliammeters
Range
0-1
0-5
0 - 15
0 - 50
0 - 100
0 - 150
0 - 250
0 - 500
Approx.
Impedance
(Ohms ) @ 60Hz
600
200
887.0
80.0
717.2
8.76
3.1
.9
2 - 1/2”
Model 155
<>
<>
<>
<>
<>
<>
06080
<>
3 - 1/2”
Model 55
<>
<>
05380
05400
05410
35069
05420
05430
*
Model / Size and Catalog No.
3 - 1/2”
Model 45 *
06820 *
06840 *
<>
<>
<>
<>
<>
<>
1
Rev. 03 - 17
Round Style
Analog Panel Meters
Ordering Information
AC Ammeters
Range
0-1
0 - 1.5
0-2
0-3
0-5
0 - 10
0 - 15
0 - 25
0 - 30
0 - 50
0 - 75
0 - 75
0 - 100
0 - 150
0 - 200
0 - 250
0 - 300
0 - 500
Iron Vane Movement
Model / Size and Catalog No.
2 - 1/2”
Model 155
02100
<>
02120
02130
02140
02150
02160
02170
02180
02190
<>
02200 *
02210 *
02220 *
<>
02240 *
<>
02260 *
3 - 1/2”
Model 55
00950
00960
00970
00980
00990
01001
01010
01020
01030
01040
03432
<>
01060 *
01070 *
01080 *
01090 *
01100 *
01110 *
Approx.
Impedance
(Ohms) @ 60 Hz
.213
.105
.065
.028
.008
.004
.0025
.002
.0015
.001
.0002
.008
.008
.008
.008
.008
.008
.008
< > Available on special order
* These meters require use of an external current transformer
AC Voltmeters
Range
0-5
0 - 10
0 - 15
0 - 25
0 - 50
0 - 100
0 - 150
0 - 250
0 - 300
0 - 500
0 - 750
Iron Vane Movement
Model / Size and Catalog No.
2 - 1/2”
Model 155
<>
<>
<>
<>
09290
<>
09310
09320
09330
09340 *
<>
3 - 1/2”
Model 55
08410
08420
08430
08440
08450
08460
08470
08480
08490
08500 *
08510 *
Approx.
Impedance
(Ohms) @ 60 Hz
33
133
300
833
3,333
16,166
25,000
41,166
50,000
83,333
125,000
< > Available on special order
* External multipliers (Model 183) are furnished on AC meters
having a range of 500 volts or higher
2
Rev. 03 - 17
Round Style
Analog Panel Meters
Ordering Information
Self-Shielding Movement
Range
Approx.
Impedance
(Ohms ) @ 60Hz
300K
Model / Size and Catalog No.
3 - 1/2”
Model 45
08010
0 - 150
4-20mA Process Meters
Range
4- 20
Approx.
Impedance (Ohms)
5.0
Dial indicates 0-100 Percent
Model / Size and Catalog No.
3 - 1/2”
Model 25
35022
Wattmeters - Dynamometer Type
Range
Volts
0 - 300
150
Maximum
Amps
4.0
Not
3 - 1/2” Model 75
10600
Model / Size and Catalog No.
Frequency Meters
Range
45 - 55 Hz
55 - 65 Hz
380 - 420 Hz
45 - 55 Hz
55 - 65 Hz
380 - 420 Hz
Voltage
120V
120V
120V
240V
240V
240V
Self-Shielding Movement
2 - 1/2”
Model 185
35154
35156
35158
35155
35157
35159
Not
3 - 1/2”
Model 85
35160
35162
35164
35161
35163
35165
Model / Size and Catalog No.
DC Microammeters
Range
0 - 50
0 - 100
0 - 200
0 - 500
50-0-50
100-0-100
500-0-500
Self-Shielding Movement
Model / Size and Catalog No.
2 - 1/2”
Model 125
04210
04220
04230
04240
04194
04196
<>
3 - 1/2”
Model 25
03760
03770
03780
03790
03810
03820
03830
Approx.
Impedance
(Ohms ) @ 60Hz
1800
1800
1100
90
1800
1100
43
< > Available on special order
3
Rev. 03 - 17
Round Style
Analog Panel Meters
Ordering Information
DC Taut-Band Microammeters
Range
0 - 10
0 - 15
0 - 25
0 - 50
0 - 100
Approx.
Impedance
(Ohms ) @ 60Hz
4900
1960
1960
960
500
Self-Shielding Movement
3 - 1/2”
Model 25T
<>
03741
03751
03761
03771
Model / Size and Catalog No.
2 - 1/2”
Model 125T
04197
<>
04201
<>
<>
< > Available on special order
DC Milliammeters
Range
0-1
0 - 1.5
0-5
0 - 10
0 - 15
0 - 25
0 - 50
0 - 75
0 - 100
0 - 150
0 - 200
0 - 250
0 - 300
0 - 500
0 - 1000
Self-Shielding Movement
Model / Size and Catalog No.
2 - 1/2”
Model 125
05580
<>
05610
05620
05630
05650
<>
05670
05680
05690
05700
05710
<>
05730
<>
3 - 1/2”
Model 25
04610
04620
04640
04650
04660
04680
04690
<>
04710
04720
04730
<>
04750
04760
04780
Approx.
Impedance
(Ohms ) @ 60Hz
43.0
43.0
2.0
10.0
6.6
4.0
2.0
1.3
1.0
.66
.5
.5
.33
.2
.05
< > Available on special order
4
Rev. 03 - 17
Round Style
Analog Panel Meters
Ordering Information
DC Ammeters
Range
0-1
0-2
0-3
0-5
0 - 10
0 - 15
0 - 25
0 - 30
0 - 50
0 - 75
0 - 100
0 - 150
0 - 200
0 - 250
0 - 300
0 - 500
0 - 750
0 - 1000
15-0-15
30-0-30
50-0-50
75-0-75
Self-Shielding Movement
Approx.
Impedance
(Ohms ) @ 60Hz
.050
.025
.0166
.010
.005
.0033
.002
.0017
.001
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
.0033
.0017
.001
20.0
Model / Size and Catalog No.
2 - 1/2”
Model 125
01460
<>
01490
01500
01510
01520
01530
01540
01550
01560 *
01570 *
01580 *
01590 *
<>
01610 *
01620
<>
<>
<>
01660
01670
35066
3 - 1/2”
Model 25
00005
00030
00040
00050
00060
00070
00080
00090
00099
00110 *
00120 *
00130 *
00140 *
00151 *
00160 *
00170 *
00177 *
00188 *
00200
00210
00220
35037 *
* DC current meters are self-contained for ranges up to and including 50 amperes
Higher range DC current meters (50 mV) listed above are calibrated for 5’ leads and
require external shunts
< > Available on special order
5
Rev. 03 - 17
