KBJ4005G - KBJ410G
4.0A GLASS PASSIVATED BRIDGE RECTIFIER
Features
·
·
·
·
·
·
·
Glass Passivated Die Construction
High Case Dielectric Strength of 1500V
RMS
Low Reverse Leakage Current
Surge Overload Rating to 120A Peak
Ideal for Printed Circuit Board Applications
UL Listed Under Recognized Component Index, File
Number E94661
Lead Free Finish, RoHS Compliant (Note 4)
Dim
A
B
C
D
E
G
H
J
K
L
M
N
KBJ
Min
24.80
14.70
17.20
0.90
7.30
3.10
Æ
3.30
1.50
9.30
2.50
3.40
4.40
0.60
Max
25.20
15.30
17.80
1.10
7.70
3.40
Æ
3.70
1.90
9.70
2.90
3.80
4.80
0.80
P
A
H
C
B
L
M
D
R
N
4.00 Nominal
Mechanical Data
·
·
·
·
·
·
·
·
·
·
Case: KBJ
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020C
Terminals: Finish - Tin. Plated Leads, Solderable per
MIL-STD-202, Method 208
e
3
Polarity: Molded on Body
Mounting: Through Hole for #6 Screw
Mounting Torque: 5.0 in-lbs Maximum
Ordering Information: See Last Page
Marking: Type Number
Weight: 4.6 grams (approximate)
_
K
E
J
G
P
R
All Dimensions in mm
Maximum Ratings and Electrical Characteristics
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
KBJ
Symbol 4005G
V
RRM
V
RWM
V
R
V
R(RMS)
@ T
C
= 115°C
I
O
I
FSM
V
FM
I
RM
I
2
t
C
T
R
qJC
T
j
, T
STG
50
35
@ T
A
= 25°C unless otherwise specified
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Rectified Output Current
Non-Repetitive Peak Forward Surge Current, 8.3 ms single
half-sine-wave superimposed on rated load
Forward Voltage per element
Peak Reverse Current
at Rated DC Blocking Voltage
I
2
t Rating for Fusing, t <8.3ms (Note 3)
Typical Total Capacitance per Element (Note 1)
Typical Thermal Resistance (Note 2)
Operating and Storage Temperature Range
Notes:
1.
2.
3.
4.
KBJ
401G
100
70
KBJ
402G
200
140
KBJ
404G
400
280
4.0
120
1.0
5.0
500
60
40
5.5
-65 to +150
KBJ
406G
600
420
KBJ
408G
800
560
KBJ
410G
1000
700
Unit
V
V
A
A
V
µA
A
2
s
pF
°C/W
°C
@ I
F
= 2.0A
@ T
C
= 25°C
@ T
C
= 125°C
Measured at 1.0 MHz and applied reverse voltage of 4.0V DC.
Thermal resistance from junction to case per element. Unit mounted on 75 x 75 x 1.6mm aluminum plate heat sink.
Non-repetitive, for t
>1ms
and
<8.3ms.
RoHs revision 13.2.2003. Glass and High Temperature Solder Exemptions Applied, see
EU Directive Annex Notes 5 and 7.
DS21206 Rev. 9 - 2
1 of 3
www.diodes.com
KBJ4005G-KBJ410G
ã
Diodes Incorporated
5
4
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
6
10
I
O
, AVERAGE RECTIFIED CURRENT (A)
T
J
= 150°C
1.0
T
J
= 25°C
3
2
1
Resistive or
Inductive load
0.1
Pulse width = 300µs
0
25
50
75
100
125
150
0.01
0
0.4
0.8
1.2
1.6
1.8
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
T
C
, CASE TEMPERATURE (°C)
Fig. 1 Forward Current Derating Curve
I
FSM
, PEAK FORWARD SURGE CURRENT (A)
180
160
Single half-sine-wave
T
j
= 150°C
1000
f = 1MHz
T
j
= 25°C
120
C
T
, TOTAL CAPACITANCE (pF)
100
80
100
40
0
1
10
NUMBER OF CYCLES AT 60 Hz
Fig. 3 Max Non-Repetitive Surge Current
10
0.1
1.0
10
100
V
R
, REVERSE VOLTAGE (V)
Fig. 4 Typical Total Capacitance, Per Element
I
R
, INSTANTANEOUS REVERSE CURRENT (µA)
1000
T
J
= 150°C
100
T
J
= 125°C
T
J
= 100°C
10
1.0
T
J
= 25°C
0.1
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
Fig. 5 Typical Reverse Characteristics
DS21206 Rev. 9 - 2
2 of 3
www.diodes.com
KBJ4005G-KBJ410G
Ordering Information
Device
KBJ4005G
KBJ401G
KBJ402G
KBJ404G
KBJ406G
KBJ408G
KBJ410G
Notes:
(Note 5)
Packaging
KBJ
KBJ
KBJ
KBJ
KBJ
KBJ
KBJ
Shipping
20/Tube
20/Tube
20/Tube
20/Tube
20/Tube
20/Tube
20/Tube
5. For packaging details, visit our website at http://www.diodes.com/datasheets/ap02008.pdf
