Crystal unit
Product Number (please contact us
)
Q22MA3062xxxx00
MHz RANGE CRYSTAL UNIT
MA - 306
Frequency
range
External
dimensions
Overtone
order
Applications
:
:
:
:
14.31818 MHz,17.734 MHz to 41 MHz
8.0 × 3.8 × 2.54 mm
Fundamental
For Clock of integrated circuit
Actual size
Specifications (characteristics)
Item
Nominal frequency range
Storage temperature
Operating temperature
Level of drive
Frequency tolerance (standard)
Frequency versus
temperature characteristics
(standard)
Load capacitance
Motional resistance (ESR)
Frequency aging
Product name
(Standard form)
Symbol
f_nom
T_stg
T_use
DL
f_tol
f_tem
CL
R
1
f_age
Specifications
14.31818 MHz,17.734 MHz to 41.000 MHz
-55
C
to +100
C
-20
C
to +70
C
10
W
to 100
W
50
10
-6
30
10
-6
Conditions / Remarks
Fundamental
Storage as single product.
10 pF to
60
Ω
Max.
5
10 / year Max.
-6
+25
C
-20
C
to +70
C
Please contact us for requirements not
listed in this specifications.
Please specify
-20
C
to +70
C,
DL=100 µW
+25
C,
First year
MA-306 24.000000MHz 12.0 +10.0-10.0
①
②
③
④
-6
①Model
②Frequency
③Load
capacitance(pF)
④Frequency
tolerance(
×
10
,
+25
C)
In addition to the above mentioned specification item, please specify frequency temperature characteristics
and operating temperature range in case of inquiry.
(Unit:mm)
External dimensions
Footprint (Recommended)
(Unit:mm)
8.0 Max.
#4
#3
E
#1
572
#2
#1
#2
2.54 Max.
2.38
0.5
5.5
Do not connect #2 and #3 to external device.
(0.9)
1.9
(0.9)
1.3
4.2
1.3
The metal case inside of the molding compound may be exposed on
the top or bottom of this product.
This purely cosmetic and does not have any effect on quality,
reliability or electrical specs.
1.9
1.3
1.9
3.2
20.000M
3.8 Max.
Internal Connection
(TOP VIEW)
#3
#4
PROMOTION OF ENVIRONMENTAL MANAGEMENT SYSTEM
CONFORMING TO INTERNATIONAL STANDARDS
At Seiko Epson, all environmental initiatives operate under the
Plan-Do-Check-Action (PDCA) cycle designed to achieve continuous
improvements. The environmental management system (EMS)
operates under the ISO 14001 environmental management standard.
All of our major manufacturing and non-manufacturing sites, in
Japan and overseas, completed the acquisition of ISO 14001
certification.
ISO 14000 is an international standard for environmental
management that was established by the International
Standards Organization in 1996 against the background of
growing concern regarding global warming, destruction of
the ozone layer, and global deforestation.
WORKING FOR HIGH QUALITY
In order provide high quality and reliable products and services
than meet customer needs,
Seiko Epson made early efforts towards obtaining ISO9000 series
certification and has acquired ISO9001 for all business
establishments in Japan and abroad. We have also acquired ISO/TS
16949 certification that is requested strongly by major automotive
manufacturers as standard.
►Explanation
of the mark that are using it for the catalog
►Pb
free.
►Complies
with EU RoHS directive.
*About the products without the Pb-free mark.
Contains Pb in products exempted by EU RoHS directive.
(Contains Pb in sealing glass, high melting temperature type solder or other.)
►Designed
for automotive applications such as Car Multimedia, Body Electronics, Remote Keyless Entry etc.
►Designed
for automotive applications related to driving safety (Engine Control Unit, Air Bag, ESC etc ).
ISO/TS16949 is the international standard that added the
sector-specific supplemental requirements for automotive
industry based on ISO9001.
