Stresses greater than the 'Absolute Maximum Ratings' specified above, may cause permanent damage to the device. These are stress ratings only; functional
operation of the device at these or any other conditions exceeding those indicated in this specification is not implied. Device reliability may be affected by exposure to
absolute maximum rating conditions for extended periods of time.
Recommended Operating Conditions
Symbol
T
OP
Parameter
Operating Junction Temperature Range
Min
0
Max
+125
Unit
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Parameter
Reference Voltage
AP1115-ADJ
AP1115-1.5
AP1115-1.8
AP1115-2.5
Output Voltage
AP1115-2.8
AP1115-3.0
AP1115-3.3
AP1115-3.5
AP1115-5.0
Line Regulation
AP1115-XXX
AP1115-ADJ
AP1115-1.5
AP1115-1.8
AP1115-2.5
Load Regulation
AP1115-2.8
AP1115-3.0
AP1115-3.3
AP1115-3.5
AP1115-5.0
Notes:
Conditions
T
A
= +25°C, (V
IN
-
OUT
) = 1.5V, I
O
= 10mA
I
OUT
= 10mA, T
A
= +25°C, 3V
≤
V
IN
≤
12V
I
OUT
= 10mA, T
A
= +25°C, 3.3V
≤
V
IN
≤
12V
I
OUT
= 10mA, T
A
= +25°C, 4V
≤
V
IN
≤
12V
I
OUT
= 10mA, T
A
= +25°C, 4.3V
≤
V
IN
≤
12V
I
OUT
= 10mA, T
A
= +25°C, 4.5V
≤
V
IN
≤
12V
I
OUT
= 10mA, T
A
= +25°C, 4.8V≤ V
IN
≤
12V
I
OUT
= 10mA, T
A
= +25°C, 5V
≤
V
IN
≤
12V
I
OUT
= 10mA, T
A
= +25°C, 6.5V
≤
V
IN
≤
12V
I
O
= 10mA, V
OUT
+ 1.5V < V
IN
< 15V, T
A
= +25°C
V
IN
= 3.3V, V
ADJ
= 0,0mA < Io < 0.6A,
T
A
= +25°C (Notes 4 & 5)
V
IN
= 3V, 0mA < Io < 0.6A,T
A
= +25°C
(Notes 4 & 5)
V
IN
= 3.3V, 0mA < Io < 0.6A, T
A
= +25°C
(Notes 4 & 5)
V
IN
= 4V, 0mA < Io < 0.6A, T
A
= +25°C
(Notes 4 & 5)
V
IN
= 4.3V, 0mA < Io < 0.6A, T
A
= +25°C
(Notes 4 & 5)
V
IN
= 5V, 0
≤
I
OUT
≤
0.6A, T
A
= +25°C
(Notes 4 & 5)
V
IN
= 5V, 0
≤
I
OUT
≤
0.6A, T
A
= +25°C
(Notes 4 & 5)
V
IN
= 5V, 0
≤
I
OU
T
≤
0.6A, T
A
= +25°C
(Notes 4 & 5)
V
IN
= 8V, 0
≤
I
OU
T
≤
0.6A, T
A
= +25°C
(Notes 4 & 5)
Min
1.225
1.470
1.764
2.450
2.744
2.940
3.235
3.430
4.900
—
—
—
—
—
—
—
—
—
—
Typ
1.250
1.500
1.800
2.500
2.800
3.000
3.300
3.500
5.000
—
—
12
15
20
22
23
26
28
40
Max
1.275
1.530
1.836
2.550
2.856
3.060
3.365
3.570
5.100
0.2
1
15
18
25
28
30
33
35
50
Unit
V
V
V
V
V
V
V
V
V
%
%
mV
mV
mV
mV
mV
mV
mV
mV
4. See thermal regulation specifications for changes in output voltage due to heating effects. Line and load regulation are measured at a constant
junction temperature by low duty cycle pulse testing. Load regulation is measured at the output lead = 1/18” from the package.
5. Line and load regulation are guaranteed up to the maximum power dissipation of 5W. Power dissipation is determined by the input/output differential
and the output current. Guaranteed maximum power dissipation will not be available over the full input/output range.
6. Quiescent current is defined as the minimum output current required to maintain regulation. At 12V input/output differential the device is guaranteed to
regulate if the output current is greater than 10mA.
7. Test conditions for SOT89-3L: Device mounted on FR-4 substrate, 2oz copper, with minimum recommended pad layout.
