206.00
[8.110]
185.05
[7.285]
D
88.10
[3.469]
88.10
[3.469]
B
58.20
[2.291]
9.53
[.375]
D
n
8.00
[.315]
110.00
[4.331]
A
96.00 90.00
[3.780] [3.543]
3.18
[.125]
n
4.50 THRU
w n
9.00 X 82.0°
A
105.05
[4.136]
Max Inner Width
M3 X 0.5 - 6H x 5.75
TOP VIEW OF BOX
190.00
[7.480]
B
SECTION B-B
C
2.09
[.082]
3.00
[.118]
C
54.70 52.40
[2.154] [2.063]
AVERAGE WALL THICKNESS
2.00
[.079]
2.50
[.098]
220.00
[8.661]
3.00
[.118]
SECTION A-A
NARROWEST INSIDE
DIMENSION
102.74
[4.045]
C
3.90
[.154]
B
88.00
[3.465]
SECTION C-C
INNER BOX HEIGHT
56.60
[2.228]
Note:
Enclosures can be Factory Modified ( Milling, Drilling, Printing etc. )
Contact Factory
mjm@hammondmfg.com for quotes
Solid models of this enclosure available in STEP or IGES Format.
B
PART NUM BERS
1591E Flanged Box Enclosures
Colour
Black
Grey
Black
Grey
Ma te ria l
FR ABS
UL94 - V0
GP ABS
Pa rt Num be r
1591EF2BK
1591EF2GY
1591EF2SBK
1591EF2SGY
Pa rt Num be r
See Accessories
Section
1591EC
1591MS100
1591MS100BK (Black)
1591TS100
1591TS100BK ( Black)
30-40 cN*m
30-40 cN*m
C
SIDE VIEW OF ASSEMBLY
n
3.00
x
8.00
w n
5.60 X 90.0°
Accessories
De scription
182.24
[7.175]
PC Board Card Adapters
2.00
[.079]
Universal Use
D
182.74
[7.195]
FR ABS
GP ABS
Clear Lids - clear, flame retardant
polycarbonate - Lid ONLY
Replacement Screws, Flat Head Phillips
Nickel Plated Pkg of 100
Self Tapping Pkg of 100
M3 - 0.5 x 10mm Screws
#4 x 0.5 Screws
102.24
[4.025]
Recomended Torque on Fasteners (no lubrication)
96.00
[3.780]
A
88.10
[3.469]
88.10
[3.469]
3.90
[.154]
D
END VIEW OF ASSEMBLY
183.05
[7.206]
A
SECTION D-D
TOP VIEW OF LID
SIDE VIEW OF LID
1591EF
2
1
4
3
