Max.
280
m /h
3
DC axial fans
92 x 38 mm
– Material:
–
–
–
–
Housing: GRP
1)
(PBT)
Impeller: GRP
1)
(PA)
Direction of air flow:
Exhaust over struts
Direction of rotation:
Clockwise,
looking towards rotor
Connection:
Via single wires AWG 24
(H3 and H4: AWG 22), TR 64
Weight:
240 g (H3 and H4: 280 g)
– Possible special versions:
(See chapter DC fans - specials)
- Speed signal
- Go / NoGo alarm
- Alarm with speed limit
- External temperature sensor
- Internal temperature sensor
- PWM control input
- Analog control input
- Moisture protection
- Degree of protection: IP 54 / IP 68
1) Fiberglass-reinforced plastic
Sintec sleeve bearings
Ball bearings
Temperature range
Nominal voltage
Sound power level
Series 3200 J
Life expectancy
L
10IPC
(40 °C) see page 17
Sound pressure level
Power consumption*
Service life L10 (40 °C)
ebm-papst standard
Service life L10 (Tmax)
ebm-papst standard
Nominal speed
Voltage range
Air flow
Air flow
Type
3212 JN
3212 JH
3212 JH3
3212 JH4
3214 JN
3214 JH
3214 JH3
3214 JH4
3218 JN
3218 JH
3218 JH3
3218 JH4
Subject to change
m
3
/h
130
146
237
280
130
146
237
280
130
146
237
280
cfm
76.5
86.0
139.5
164.8
76.5
86.0
139.5
164.8
76.5
86.0
139.5
164.8
VDC
12
12
12
12
24
24
24
24
48
48
48
48
VDC
7...13.8
7...15
6...13.8
6...13.8
11...28
12...30
12...27.6
12...27.6
36...56
36...53
20...58.0
20...58.0
dB(A) Bel(A)
51
55
69
73
51
55
69
73
51
55
69
73
6.1
6.4
7.8
8.2
6.1
6.4
7.8
8.2
6.1
6.4
7.8
8.2
/
Watts
7.5
9.0
31.0*
50.0*
6.5
9.0
30.0*
50.0*
7.0
9.5
29.0*
50.0*
rpm
-1
6 000
6 800
11 000
13 000
6 000
6 800
11 000
13 000
6 000
6 800
11 000
13 000
°C
-20 ...+70
-20 ...+70
-20 ...+70
-20 ...+70
-20 ...+70
-20 ...+70
-20 ...+70
-20 ...+70
-20 ...+70
-20 ...+70
-20 ...+70
-20 ...+70
Hours
70 000 / 35 000
70 000 / 35 000
65 000 / 32 500
60 000 / 30 000
70 000 / 35 000
70 000 / 35 000
65 000 / 32 500
60 000 / 30 000
70 000 / 35 000
70 000 / 35 000
65 000 / 32 500
60 000 / 30 000
Hours
117 500
117 500
110 000
110 000
117 500
117 500
110 000
110 000
117 500
117 500
110 000
110 000
¿
¡
¬
√
¿
¡
¬
√
¿
¡
¬
√
3200 JH3 and JH4 also available as standard with PWM control input and speed signal.
Speed control range from 2000 rpm
-1
up to maximum nominal speed. Standstill at 0% PWM, maximum speed if control cable is interrupted.
* Power consumption at free air flow. These values can be significantly higher in the operating point.
Tin-p
la
ted
51
2016-01
Finger guards
from p. 242
Representatives
Air performance measured according to: ISO 5801.
Installation category A, without contact protection.
Noise: Total sound power level L
W
A ISO 103002
measured on a hemisphere with a radius of 2 m.
Sound pressure level LpA measured at 1 m distance
from fan axis.
The values given are applicable only under the specified
measuring conditions and may differ depending on the
installation conditions.
In the event of deviation from the standard configuration,
the parameters must be checked after installation!
For detailed information see
http://www.ebmpapst.com/general conditions
Accessories
AC centrifugal fans
AC axial fans
ACmaxx / EC fans
DC fans - specials
Nominal data
Curve
DC centrifugal fans
DC axial fans
Information
Speed signal /2
–
–
–
–
–
–
–
