DC Fan
60
San Ace 60
mm sq.
■
General Specifications
・
Material
……………………
Frame: Plastics (Flammability: UL94V-0),
Impeller: Plastics (Flammability: UL94V-0)
・
Expected Life
……………
Refer to specifications L10:Survival rate:90% at 60
℃
,
（
rated voltage, and continuously run in a free air state
）
・
Lead Wire
…………………⊕
red
⊖
black
Sensor
yellow
Control
brown
・
Storage Temperature
…−
30
℃
to
＋
70
℃（
Non-condensing
）
60
×
60
×
38
mm
■
Specifications
Model No.
［
V
½
〔
Mass
：
135g
〕
9HV
type
The following nos.
have PWM controls, pulse sensors, and ribs
. For ribless, append "1" to the model no.
Rated Voltage Operating Voltage Range
［
V
½
PWM duty
Rated Current Rated Input Rated Speed
Max. Airflow
Max. Static Pressure
SPL
Operating Temperature Range Expected Life
［
W
½
［
min
-1
½
［
m³/min
½ ［
CFM
½ ［
Pa
½ ［
inchH²O
½ ［
dB(A)
½
［℃½
［
h
½
cycle
Note)
※
［
%
½ ［
A
½
9HV0612P1J001
12
10.8 to 12.6
100
20
2.7
0.17
32.4
2.04
21,700
5,300
1.88
0.43
66.4
15.2
1,750
102
7.00
0.41
68
34
−
20 to
＋
70
40,000/60
℃
(70,000/40
℃
)
Note: Fan does not rotate when PWM duty cycle is 0%.
※
PWM Frequency
：
25kHz
■
Dimensions
（
unit: mm
）
With ribs
）
（
4-
φ
4.5
±
0.3
Mounting Hole
取付用穴
+50
300 0
■
Reference Dimensions of
Mounting Holes and Vent Opening
（
unit: mm
）
Inlet side, Outlet side
59
50
±
0.3
29.7
4-
φ
4.5
60
±
0.5
50
±
0.3
(10)
AWG24
UL1430
4
±
0.3
50
±
0.3
60
±
0.5
Rotating Direction
回転方向
62
.7
Lead Wire
リー
ド線
29.7
50
±
0.3
6.5±0.5
4-2±0.5
4-φ4.3±0.3
質量：7g
Mass
4
±
0.3
38
±
0.5
Airflow Direction
風吹出方向
■
Options
（
unit: mm
）
Finger Guards
Model
：
109-139E
：
109-139H
Color
Surface treatment
：
Nickel-chrome plating silver
）
（
：
Cation electropainting black
）
（
Resin Finger Guards
Model
：
109-1003G
Inlet side, Outlet side
4.3±0.3
φ1.6
φ1.6
62
＋1
4
0
60.5±1
50±0.3
φ53
＋1.5
ー0.5
60.5±1
φ70.7
質量：14.5g
Mass
77
50±0.3
75
59
