The D1U5CS-H-2825 is a 2825 Watt, power-factor-corrected (PFC) front-end power supply for redundant systems. The
main output is 12V and the standby output is 5V. Packaged in 1U low profile, it is designed to deliver reliable bulk power
to servers, workstations, storage systems or any 12V distributed power architecture system requiring high power density.
The highly efficient electrical and thermal design with internal cooling fans supports reliable operating conditions. The
D1U5CS-H-2825 is designed to autorecover from over-temperature faults. Status information is provided with front panel
LEDs, logic signals and I
2
C management interface.
ORDERING GUIDE
Model Number
D1U5CS-H-2825-12-HA4C
Power Output Main Output Standby Output
2825W
12V
5V
Airflow
Back to front, variable
Connector
AC front
FEATURES
n
2825W (220Vac) Output power
n
Certified to Climate Savers Computing
Initiative
SM
80 PLUS
®
Gold efficiency
n
Main output, 5V standby output
12V
n
sized; dimensions 5.1”x14.4”x1.61”
1U
n
Watts per cubic inch density
23.9
n
redundancy capable, including hot
N+1
plugging (up to 3 in parallel)
n
Active current sharing on main output,
ORing FET
n
Overvoltage, Overcurrent,
Overtemperature protection
n
Internal cooling fans (variable speed)
n
Bus Interface with status indicators
I²C
n
compliant
RoHS
INPUT CHARACTERISTICS
Parameter
Voltage Operating Range
Frequency
Maximum Current
Inrush Current
Power Factor
Efficiency (230Vac) excludes fan load
Conditions
Min.
180
47
Typ.
60
Max.
264
63
16
90
Units
Vac
Hz
Arms
Apk
230Vac
At 230Vac, full load
20% load
50% load
100% load
0.95
88.31
92.63
92.05
%
OUTPUT VOLTAGE CHARACTERISTICS
Output
Voltage
Parameter
Voltage Set Point Accuracy
Line and Load Regulation
Ripple Voltage & Noise
1
Output Current
Load Capacitance
Voltage Set Point Accuracy
Line and Load Regulation
Ripple Voltage & Noise
1
Output Current
Load Capacitance
Conditions
Min.
11.75
Typ.
12.12
Max.
12.48
120
233
2200
Units
Vdc
mV p-p
A
µF
Vdc
mV p-p
A
µF
12V
20MHz Bandwidth
0
0
5.0
4.85
20MHz Bandwidth
0
0
5Vsb
5.15
50
4
200
OUTPUT CHARACTERISTICS
Parameter
Startup Time
Conditions
AC ramp up
PS_On activated
12V Ramp 1A/μs
load capacitance is 2200μF
5Vsb Ramp 1A/μs
load capacitance is 200μF
At 100% load
20% load
Min.
Typ.
1.5
150
Max.
Units
s
ms
±600
mV
±250
±10
12
88.3
120
%
ms
mV
Transient Response
Current sharing accuracy (up to 3 in
parallel)
Holdup Time
Remote Sense
1 Ripple and noise are measured with 0.1 µF of ceramic capacitance and 10 µF of tantalum capacitance on each of the power supply outputs. A short coaxial
cable with 50ohm scope termination is used.
For full details go to
www.murata-ps.com/rohs
CB
Test Certificate
and Test Report
www.murata-ps.com/support
D1U5CS-H-2825-12-HA4C.A01
Page 1 of 5
D1U5CS-H-2825-12-HA4C
AC/DC Front End Power Supply
ENVIRONMENTAL CHARACTERISTICS
Parameter
Storage Temperature Range
Operating Temperature Range
Operating Humidity
Storage Humidity
Shock
Sinusoidal Vibration
MTBF
Acoustic
Safety Approvals:
Input Fuse
Material Flammability
Switching Frequency
Weight
Conditions
Non-condensing
Non-condensing
30G non operating
0.5G, 5 – 500 Hz
Calculated per Telecordia SR322M1C2
Ta = 30°C
Ta = 40°C
ISO 7779-1999
Min.
-40
0
10
5
Typ.
Max.
70
50
90
90
Units
°C
%
716,317
484,059
hrs
c-CSA-US (CSA 60950-1-03/UL 60950-1, Second Edition
