ITEM #
1
2
3
4
5
6
7
8
9
10
11
PART #
8
QTY
DESCRIPTION
SHELL ASS'Y
INSERT ASS'Y
STRAIN RELIEF
WASHER
NUT ADAPTER
7
MATERIAL
6
5
4
AP-135-1
AP-125-6
AP-105-5
AP-116-3
AP-136-8
AP-136-6
AP-136-5
AP-116-8
AP-116-2
AP-116-4
AP-116-6
1
1
1
1
1
1
1
1
1
1
1
GLASS FILLED NYLON & 303 SS
DIALLYPHTHALATE, TYPE SDGF
& GOLD PLATED BRASS
NYLON
RUBBER
ALUMINUM, BLACK CHROME
NICKEL PLATED BRASS
NICKEL PLATED BRASS
RUBBER
STAINLESS STEEL
302 STAINLESS STEEL
ANODIZED ALUMINUM ALLOY
C
AP-135
3
2
1
D
CLAMP SHIELD, OUTER
CLAMP SHIELD INNER
BUSHING
WASHER
SPRING
STUD
11
6
5
4
3
2
1
ORANGE
ALIGNMENT
MARK
7
9
8
10
D
C
C
36°
Z
12°
3.41
.834
12°
B
1.022
B
Z
.344
SECTION Z-Z
NOTES:
1) UNLESS OTHERWISE SPECIFIED, CONNECTOR MEETS ALL
GENERAL REQUIREMENTS & SPECIFICATIONS OF MIL-C-55116
THIS DOCUMENT CONTAINS PROPRIETARY INFOR-
MATION OF NEXUS,INCORPORATED AND SUCH
INFORMATION MAY NOT BE DISCLOSED TO OTHERS
FOR ANY PURPOSE OR USED FOR ANY PURPOSE
WITHOUT THE WRITTEN CONSENT OF NEXUS.
DWN.BY
A
MNF
L SMITH
APPR.BY
DATE
A
2/4/97
MATERIAL
FINISH
WEIGHT
TITLE
SCALE = 1.00 :1
CHECKED BY
DATE
9/9/97
9/9/97
DATE
L SMITH
B
A
LET.
ADD P/N'S IN P/L
REVISED & REDRAWN
ON CAD
REVISION
101
0259
CN #
2/25
2011
2/24
1997
DATE
HR
LS
CHK
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES &/OR [mm]
TOLERANCES:
DECIMAL: ±.XX[X.X]
± .01[0.3]
FRACTION: ±X/X
± 1/64
±.XXX[X.XX]
± .003[0.08]
ANGLES: ±.X
± .5
AUDIO PLUG
DO NOT SCALE DWG.
SHEET 1 OF 1
STAMFORD,CONN
NEXUS
DWG. NO.
C
SIZE
AP-135
