This document was generated on 02/27/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0877159006
Active
PCI Express* Card Edge Connector
1.00mm Pitch, PCI Express Connector, 36 Circuits, Nylon 4/6 Glass-filled, Black
Housing, Phosphor Bronze, 0.76µm Gold Soldertail, Lead-Free
Documents:
Drawing (PDF)
Product Specification PS-87715-200-001 (PDF)
Product Specification TS-87715-207-001 (PDF)
Agency Certification
CSA
UL
General
Product Family
Series
Comments
Component Type
Data Rate
Edge Card Thickness
Electrical Model
High Power Bay (30.0A or more)
Orientation
Overview
Product Name
Standard Based
UPC
Physical
(p)ower-(s)ignal Configuration
Circuit Size Range
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
Entry Angle
Flammability
Keying to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Plating min - Termination
Polarized to Mating Part
Temperature Range - Operating
Termination Interface: Style
Packaging Specification PK-87715-001 (PDF)
Packaging Specification PK-87715-207 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
LR19980
E29179
Edge Card Connectors
87715
PCI 1 lane
Edgecard to PCB
8.0 Gbps
1.57mm
Yes
No
Vertical
PCI Express* Card Edge Connector
PCI Express
PCIe
822348679836
36s - 0p
1-64 Circuits
36
36
Black
50
Vertical (Top Entry)
94V-0
Yes
Phosphor Bronze
Gold
Tin
High Temperature Thermoplastic
2.867/g
2.54mm
Yes
Yes
1.60mm
Tray
1.00mm
1.00mm
0.762µm
2.540µm
Yes
-55°C to +85°C
Through Hole
EU ELV
Not Relevant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per
-ED/01/2018 (15
January 2018)
Halogen-Free
Status
Not Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
Search Parts in this Series
87715 Series
Mates With
PCI Express Card
Electrical
Current - Maximum per Contact
Voltage - Maximum
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-freeProcess Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
Material Info
Reference - Drawing Numbers
Electrical Model Document
Packaging Specification
Product Specification
S-Parameter Model
Sales Drawing
Signal Integrity Report
1.1A
50V AC (RMS)/DC
010
REFLOW
001
260
EE-87715-002, EE-87715-011, EE-87715-012,
EE-87715-013, EE-87715-014
PK-87715-001, PK-87715-207
PS-87715-200-001, TS-87715-207-001
SP-87715-002, SP-87715-011, SP-87715-012,
SP-87715-013, SP-87715-014
SD-87715-901
SI-87715-002
