with Strain Relief
Type D - Direct Coupling - Low Pro le
See inside back cover fold-out or pages 13 and 14 for unabridged Tables I and II.
Shell
Size
08/09
10/11
12/13
14/15
16/17
18/19
20/21
22/23
24/25
28/29
32/33
36
40
Dash
No.
04
06
08
10
12
16
20
24
28
32
TABLE III: FRONT ADAPTER
J Max - Conn. Designator
A-E-F
C
J-H-L-S
D-B-G-K
1.180 (30.0) 1.440 (36.6)
1.180 (30.0) 1.440 (36.6)
1.180 (30.0) 1.440 (36.6) 1.735 (44.1)
1.180 (30.0) 1.440 (36.6) 1.915 (48.6)
1.380 (35.0) 1.560 (39.6) 1.915 (48.6)
1.380 (35.0) 1.560 (39.6) 1.915 (48.6)
1.380 (35.0) 1.560 (39.6) 1.915 (48.6)
1.380 (35.0) 1.560 (39.6) 1.915 (48.6)
1.380 (35.0) 1.560 (39.6) 1.915 (48.6)
1.610 (40.9) 1.560 (39.6) 1.915 (48.6)
1.610 (40.9) 1.750 (44.5) 1.915 (48.6)
1.610 (40.9) 1.750 (44.5) 1.915 (48.6)
1.610 (40.9) 2.190 (55.6) 1.915 (48.6)
TABLE IV: ELBOW DIMENSIONS
F
Elbow
E
G
Max
Size
Max
Max
03 .630 (16.0) 1.730 (43.9) .636 (16.2)
04 .630 (16.0) 1.730 (43.9) .636 (16.2)
06 .630 (16.0) 1.730 (43.9) .710 (18.0)
08 .692 (17.6) 1.790 (45.5) .731 (18.6)
10 .755 (19.2) 1.880 (47.8) .825 (21.0)
12 .848 (21.5) 1.990 (50.5) .988 (25.1)
16 1.036 (26.3) 2.180 (55.4) 1.087 (27.6)
20 1.130 (28.7) 2.330 (59.2) 1.325 (33.7)
24 1.255 (31.9) 2.380 (60.5) 1.337 (34.0)
28 1.317 (33.5) 2.480 (63.0) 1.827 (46.4)
32 1.348 (34.2) 2.570 (65.3) 2.027 (51.5)
TABLE II: STANDARD FINISHES
GLENAIR
SYMBOL
B
M
NF
FINISH
Cadmium Plate, Olive Drab
Electroless Nickel
Cadmium Plate, Olive Drab
Over Electroless Nickel
H
Max
1.680 (42.7)
1.680 (42.7)
1.800 (45.7)
1.820 (46.2)
1.890 (48.0)
1.980 (50.3)
2.150 (54.6)
2.260 (57.4)
2.430 (61.7)
2.680 (68.1)
2.680 (68.1)
TABLE X: CABLE ENTRY
V
Cable Range
T
Max
Max
Min
Max
.780 (19.8)
.957 (24.3)
.125 (3.2) .312 (7.9)
.780 (19.8) 1.145 (29.1)
.250 (6.4) .437 (11.1)
.780 (19.8) 1.332 (33.8)
.312 (7.9) .562 (14.3)
.350 (8.9) .625 (15.9)
.780 (19.8) 1.332 (33.8)
.811 (20.6) 1.551 (39.4)
.500 (12.7) .750 (19.1)
.905 (23.0) 1.770 (45.0)
.625 (15.9) .937 (23.8)
.875 (22.2) 1.250 (31.8)
1.092 (27.7) 2.113 (53.7)
1.124 (28.5) 2.363 (60.0) 1.000 (25.4) 1.375 (34.9)
1.399 (35.5) 2.770 (70.4) 1.250 (31.8) 1.625 (41.3)
1.399 (35.5) 3.020 (76.7) 1.437 (36.5) 1.875 (47.6)
See Inside Back Cover
for Additional Finish Options
TABLE XI: CABLE ENTRY
Dash
Z
Y
X
W
No.
Max
Max
Max
Max
03* .437 (11.1) .760 (19.3) .843 (21.4)
.630 (16.0)
04* .437 (11.1) .760 (19.3) .906 (23.0)
.755 (19.2)
06* .500 (12.7) .760 (19.3) 1.093 (27.8)
.942 (23.9)
08 .563 (14.3) .760 (19.3) 1.187 (30.1) 1.067 (27.1)
10 .563 (14.3) .760 (19.3) 1.281 (32.5) 1.192 (30.3)
12 .563 (14.3) .760 (19.3) 1.500 (38.1) 1.380 (35.1)
16 .656 (16.7) 1.073 (27.3) 1.719 (43.7) 1.535 (39.0)
20 .656 (16.7) 1.323 (33.6) 2.062 (52.4) 1.848 (46.9)
24 .656 (16.7) 1.323 (33.6) 2.312 (58.7) 2.255 (57.3)
28 1.188 (30.2) 1.572 (39.9) 2.719 (69.1) 2.505 (63.6)
32* 1.187 (30.1) 1.572 (39.9) 2.969 (75.4) 2.755 (70.0)
40* 1.125 (28.6) 1.572 (39.9) 3.531 (89.7) 3.255 (82.7)
* Not available in Style M clamp.
