KTA501E datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> KTA501E

KTA501E: DescriptionEPITAXIAL PLANAR PNP TRANSISTOR (GENERAL PURPOSE, SWITCHING); CategoryDiscrete semiconductor The transistor; File Size396KB，3 Pages; ManufacturerKEC; Websitehttp://www.keccorp.com/

Download Datasheet Parametric View All

KTA501E Overview

EPITAXIAL PLANAR PNP TRANSISTOR (GENERAL PURPOSE, SWITCHING)

KTA501E Parametric

Parameter Name	Attribute value
Maker	KEC
package instruction	SMALL OUTLINE, R-PDSO-F5
Contacts	5
Reach Compliance Code	unknown
ECCN code	EAR99
Maximum collector current (IC)	0.15 A
Collector-emitter maximum voltage	50 V
Configuration	COMMON EMITTER, 2 ELEMENTS
Minimum DC current gain (hFE)	120
JESD-30 code	R-PDSO-F5
Number of components	2
Number of terminals	5
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Polarity/channel type	PNP
Certification status	Not Qualified
surface mount	YES
Terminal form	FLAT
Terminal location	DUAL
transistor applications	SWITCHING
Transistor component materials	SILICON
Nominal transition frequency (fT)	80 MHz
Base Number Matches	1

Preview

Download Datasheet

View All

SEMICONDUCTOR

TECHNICAL DATA

GENERAL PURPOSE APPLICATION.

SWITCHING APPLICATION.

KTA501E

EPITAXIAL PLANAR PNP TRANSISTOR

FEATURES

A super-minimold package houses 2 transistor.

High pairing property in h

The follwing characteristics are common for Q

, Q

Excellent temperature response between these 2 transistor.

DIM

MILLIMETERS

1.6 + 0.05

1.0 + 0.05

1.6 + 0.05

_ 0.05

1.2+

0.50

0.2 + 0.05

_ 0.05

0.5 +

0.12 + 0.05

MAXIMUM RATING (Ta=25

CHARACTERISTIC

Collector-Base Voltage

Collector-Emitter Voltage

Emitter-Base Voltage

Collector Current

Base Current

Collector Power Dissipation

Junction Temperature

Storage Temperature Range

* Total Rating

)

CBO

CEO

EBO

stg

-50

-5

-150

-30

200

150

-55 150

1. Q

BASE

2. Q

, Q

EMITTER

3. Q

BASE

4. Q

COLLECTOR

5. Q

COLLECTOR

SYMBOL

RATING

UNIT

TESV

EQUIVALENT CIRCUIT (TOP VIEW)

ELECTRICAL CHARACTERISTICS (Ta=25 )

CHARACTERISTIC

Collector Cut-off Current

Emitter Cut-off Current

DC Current Gain

Collector-Emitter Saturation Voltage

Transition Frequency

Collector Output Capacitance

Noise Figure

SYMBOL

CBO

EBO

(Note)

CE(sat)

TEST CONDITION

=-50V, I

=-5V, I

=-6V, I

=-2

=-100

, I

=-10

MIN.

120

, Rg=10

TYP.

-0.1

1.0

Type Name

MAX.

-0.1

400

-0.30

UNIT.

=-10V, I

=-1

=-10V, I

=0, f=1

=-6V, I

=-0.1

, f=1

Note : h

Classification Y(4):120 240, GR(6):200 400

Marking

Rank

2003. 2. 25

Revision No : 2

1/3
