DUAL-IN-LINE
SOCKETS
SERIES 110...605 • AUTOMATIC INSERTION • OPEN FRAME
•
High temperature thermoplastic insulator
.018-.025
.010 .018
B
with stando s is compatible with standard
automatic insertion equipment and all
soldering processes
ing. Chamfered contact entry allows for ease
of IC insertion without bent leads
3 amps. See page 253 for details
for details
.146
.095
•
Soft copper alloy machined pins allow clinch-
.117
.165
.125
•
Hi-Rel, 4- nger BeCu #30 contact is rated at
•
Series 110 uses MM #1005 pins. See page 166
•
For Electrical, Mechanical and Environmental
Data, see page 264 for details
.020 DIA.
See page 132 for Insulator Details
Total number
of pins
A
B
.100
C
Quantity
per tube
ORDERING INFORMATION
A
0.3
0.4
0.7
0.8
0.9
1.0
1.2
1.1
1.2
1.4
1.6
2.0
B
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.4
0.6
0.6
0.6
0.6
C
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.5
0.7
0.7
0.7
0.7
6
8
14
16
18
20
24
22
24
28
32
40
67
50
28
25
22
20
16
18
16
14
12
10
110-XX-306-41-605000
110-XX-308-41-605000
110-XX-314-41-605000
110-XX-316-41-605000
110-XX-318-41-605000
110-XX-320-41-605000
110-XX-324-41-605000
110-XX-422-41-605000
110-XX-624-41-605000
110-XX-628-41-605000
110-XX-632-41-605000
110-XX-640-41-605000
PAGE 94 | IC SOCKETS / TO SOCKETS
XX=Plating Code
See Below
2011/65/EU
RoHS - 2
SPECIFY PLATING CODE XX =
Sleeve (Pin)
Contact (Clip)
91
200
µ”
Sn/Pb
10
µ”
Au
93
200
µ”
Sn/Pb
30
µ”
Au
41
200
µ”
Sn
10
µ”
Au
43
200
µ”
Sn
30
µ”
Au
47
200
µ”
Sn
Au Flash
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
