715C..KT...
www.vishay.com
Vishay Cera-Mite
High Voltage Class 1 Ceramic DC Disc Capacitors,
Screw Terminal Mounting, 10 kV
DC
to 40 kV
DC
FEATURES
•
•
•
•
•
•
•
•
•
Low dissipation factor of 0.2 % at 1 kHz
N4700 (T3M) class 1, strontium-based ceramic dielectric
Negligible piezoelectric / electrostrictive effect
Low inductance
High insulation resistance
Epoxy coating
Screw terminal mounting
Ceramic singlelayer capacitor
Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
APPLICATIONS
QUICK REFERENCE DATA
DESCRIPTION
Ceramic Class
Ceramic Dielectric
Type
Voltage (V
DC
)
Min. Capacitance (pF)
VALUE
1
N4700
715C10 715C15 715C20 715C30 715C40
KT### KT### KT### KT### KT###
10 000 15 000 20 000 30 000 40 000
560
370
5300
280
4000
190
2700
140
2000
•
•
•
•
•
High voltage power supplies
CO
2
lasers
X-ray equipment
Welding equipment
Industrial
CAPACITANCE RANGE
140 pF to 8 nF
RATED VOLTAGE
•
•
•
•
•
(1)
Max. Capacitance (pF) 8000
Mounting
Screw terminal
DIELECTRIC STRENGTH
150 % of rated voltage, charging current limited to 50 mA
10 kV
DC
(3.5 kV
RMS
)
15 kV
DC
(5.3 kV
RMS
)
20 kV
DC
(7.0 kV
RMS
)
30 kV
DC
(10.6 kV
RMS
)
40 kV
DC
(14 kV
RMS
)
Note
(1)
All kV
RMS
values up to 60 Hz
DISSIPATION FACTOR tan
2x
10
-3
(1 kHz)
CERAMIC DIELECTRIC
N4700 (class 1)
INSULATION RESISTANCE
Min. 200 000 M or 1000
F
min. at 25 °C
MATERIAL
Capacitor elements made from class 1 ceramic in a molded
epoxy case. Screw terminals: brass, silver plated.
CORONA LIMIT
< 5 pC at rated AC voltage
MARKING
Type designator, capacitance value, rated DC voltage,
ceramic material code, production date code, Cera-Mite
logo.
OPERATING TEMPERATURE RANGE
-30 °C to +85 °C
POWER DISSIPATION
Limit to 25 °C rise above ambient, measured on case.
CAPACITANCE TOLERANCES
± 20 %
Revision: 19-Jan-17
Document Number: 22210
1
For technical questions, contact:
powcap@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
715C..KT...
www.vishay.com
DIMENSIONS
in millimeters (inches)
8-32NC-2B tapped holes
standard
terminal
(1)
or
M5 tapped holes
(2)
D ± 1 (0.04)
Vishay Cera-Mite
H ± 1 (0.04)
Notes
(1)
Screw torque limit must be 12 inch pounds. Use #8-32, 3/16" long screw to prevent bottoming
(2)
To order M5 terminals add “M5” suffix to model number, use screw length of 5 mm to prevent bottoming
ORDERING INFORMATION
715C15KTD33
MODEL
15 kV
DC
RATED VOLTAGE
3300 pF
CAPACITANCE VALUE
± 20 %
TOLERANCE
N4700
CERAMIC
SAP PART NUMBER, ELECTRICAL, AND DIMENSIONAL DATA
MODEL
715C10KT###
715C10KTT56
715C10KTD10
715C10KTD12
715C10KTD22
715C10KTD28
715C10KTD50
715C10KTD80
715C15KT###
715C15KTT37
715C15KTD10
715C15KTD19
715C15KTD33
715C15KTD53
715C20KT###
715C20KTT28
715C20KTT56
715C20KTD10
715C20KTD14
715C20KTD25
715C20KTD40
715C30KT###
715C30KTT19
715C30KTT40
715C30KTT59
715C30KTT94
715C30KTD17
715C30KTD27
715C40KT###
715C40KTT14
715C40KTT44
715C40KTT70
715C40KTD10
715C40KTD13
715C40KTD20
Revision: 19-Jan-17
CERAMIC
CAPACITANCE
VALUES
(pF)
560
1000
1200
2200
2800
5000
8000
370
1000
1900
3300
5300
280
560
1000
1400
2500
4000
190
400
590
940
1700
2700
140
440
700
1000
1300
2000
RATED
VOLTAGE
(kV
DC
)
RATED
VOLTAGE
(kV
RMS
)
D ± 1 mm
(0.04")
21 (0.83)
25 (0.98)
25 (0.98)
38 (1.50)
38 (1.50)
48 (1.89)
60 (2.36)
21 (0.83)
32 (1.26)
38 (1.50)
48 (1.89)
60 (2.36)
21 (0.83)
25 (0.98)
32 (1.26)
38 (1.50)
48 (1.89)
60 (2.36)
21 (0.83)
32 (1.26)
32 (1.26)
38 (1.50)
48 (1.89)
60 (2.36)
21 (0.83)
32 (1.26)
38 (1.50)
44 (1.73)
48 (1.89)
60 (2.36)
H WITH #8-32
TERMINALS
± 1 mm (0.04")
H WITH M5 METRIC
TERMINALS
± 1 mm (0.04")
n/a
18 (0.71)
19 (0.75)
N4700
10
3.5
n/a
n/a
20 (0.79)
22 (0.87)
N4700
15
5.3
n/a
n/a
23 (0.91)
24 (0.94)
N4700
20
7
n/a
n/a
28 (1.10)
29 (1.14)
N4700
30
10.6
n/a
31 (1.22)
N4700
40
14
32 (1.26)
Document Number: 22210
2
For technical questions, contact:
powcap@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
715C..KT...
www.vishay.com
CAPACITANCE CHANGE VS. VOLTAGE
(typical)
10
0
-10
-20
-30
-40
-50
-60
-70
-80
-90
-100
0
Vishay Cera-Mite
ᐃC/C
(%)
T3M (N4700)
ΔC/C
= f (U
R
)
10
20
30
40
50
60
70
80
90
100
U
R
(%)
Note
• Curve valid for 715C..KT.., except: 715C10KTD10, 715C10KTD12, and 715C10KTD22
