Type Q/QRL
(Quencharc
) Arc Suppressor/Snubber Network
Radial Metallized Polyester RC Network for Transient Suppression
QUENCHARC
QUENCHARC
Arc Suppressor
Snubber Network
"ARCING", "SPARKING", and "TRANSIENTS" often
cause premature failures in relays, switches, thyristors,
triacs, contactors, and related products. QUENCHARC
extends operating life when properly selected and applied.
Highlights
♦
Specifications
♦
♦
♦
♦
♦
♦
♦
♦
Noise and arc suppression
RC Snubber Network
Relay contact protection
Noise reduction on controllers and drives
EMI/RFI reduction
dv/dt suppression
Type QRL - UL/CSA verison
Coated with flame retardant epoxy
Halogen-free (date codes 1807 and after)
Outline Dimensions
L Max.
T
Max.
QUENCHARC
H Max.
.850" Min.
.25" Max.
d
S Typ.
Capacitance Range:
Voltage Range:
Capacitance Tolerance:
Resistor Tolerance:
Resistor Values:
Operating Temperature Range :
Construction:
Dielectric Withstand Voltage:
DC Life Test:
0.10 µF, 0.25 µF, 0.50 µF, 1.0 µF
200 Vdc/125 Vac, 60 Hz thru 1600 Vdc/660 Vac, 60 Hz
±20%
±10%
22, 39, 47, 100, 150, 220, 330, 680 ohms
–55 ºC to +85 ºC at full rated voltage
Metallized polyester in series with a carbon composition resistor
1
1.6 x DC rated voltage @ +25 ºC
125% of rated voltage for a period of 500 hours at 85 ºC with
capacitance change
≤5%
and DF
≤
original limits
Long Term Stability:
The capacitance shall not change more than 2% when stored
at ambient temperature and humidity for a period of two years or less.
RoHS Compliant
Ratings
Catalog
Part Number
Cap
(uF)
Resistor
Ohms Watts
L
Max
1.08
1.08
1.08
1.08
T
Max
0.37
0.37
0.37
0.37
H
Max
0.64
0.64
0.64
0.64
Dimensions in Inches
S
Typ.
0.82
0.82
0.82
0.82
Ød
C
Typ.
0.032
0.032
0.032
0.032
Ød
r
Typ.
0.025
0.025
0.025
0.025
L
Max
27.4
27.4
27.4
27.4
Dimensions in Millimeters
T
Max
9.4
9.4
9.4
9.4
H
Max
16.3
16.3
16.3
16.3
S
Typ.
20.8
20.8
20.8
20.8
Ød
C
Typ.
0.8
0.8
0.8
0.8
Ød
r
Typ.
0.635
0.635
0.635
0.635
200 Vdc / 125Vac
504M02QA22
504M02QA47
504M02QA100
504M02QA220
0.5
0.5
0.5
0.5
22
47
100
220
1/2
1/2
1/2
1/2
105M02QB22
105M02QB47
104M06QC22
104M06QC47
104M06QC100
104M06QC150
104M06QC220
104M06QC330
1.0
1.0
0.1
0.1
0.1
0.1
0.1
0.1
22
47
22
47
100
150
220
330
1/2
1/2
1/2
1/2
1/2
1/2
1/2
1/2
1.45
1.45
1.08
1.08
1.08
1.08
1.08
1.08
0.39
0.39
0.39
0.39
0.39
0.39
0.39
0.39
0.66
0.66
0.66
0.66
0.66
0.66
0.66
0.66
1.20
1.20
0.82
0.82
0.82
0.82
0.82
0.82
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.025
0.025
0.025
0.025
0.025
0.025
0.025
0.025
36.8
36.8
27.4
27.4
27.4
27.4
27.4
27.4
9.9
9.9
9.9
9.9
9.9
9.9
9.9
9.9
16.7
16.7
16.7
16.7
16.7
16.7
16.7
16.7
30.5
30.5
20.8
20.8
20.8
20.8
20.8
20.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.635
0.635
0.635
0.635
0.635
0.635
0.635
0.635
600 Vdc / 250Vac
Type QRL: UL File No. E33628, CSA File No. LR32208
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.cde.com
Type Q/QRL
(Quencharc
) Arc Suppressor/Snubber Network
Ratings
Resistor
Catalog
Part Number
Cap
(µF)
Ohms Watts
L
Max
T
Max
Dimensions in Inches
H
Max
S
Typ.
Ød
C
Typ.
Ød
r
Typ.
L
Max
Dimensions in Millimeters
T
Max
H
Max
S
Typ.
Ød
C
Typ.
Ød
r
Typ.
600 Vdc / 250Vac
254M06QD22
254M06QD47
254M06QD100
254M06QD150
0.25
0.25
0.25
0.25
22
47
100
150
1/2
1/2
1/2
1/2
1.45
1.45
1.45
1.45
0.42
0.42
0.42
0.42
0.75
0.75
0.75
0.75
1.20
1.20
1.20
1.20
0.032
0.032
0.032
0.032
0.025
0.025
0.025
0.025
36.8
36.8
36.8
36.8
10.6
10.6
10.6
10.6
19.0
19.0
19.0
19.0
30.5
30.5
30.5
30.5
0.8
0.8
0.8
0.8
0.635
0.635
0.635
0.635
504M06QE22
504M06QE47
504M06QE100
504M06QE150
0.5
0.5
0.5
0.5
22
47
100
150
1/2
1/2
1/2
1/2
1.45
1.45
1.45
1.45
0.59
0.59
0.59
0.59
0.92
0.92
0.92
0.92
1.20
1.20
1.20
1.20
0.032
0.032
0.032
0.032
0.025
0.025
0.025
0.025
36.8
36.8
36.8
36.8
15.0
15.0
15.0
15.0
23.4
23.4
23.4
23.4
30.5
30.5
30.5
30.5
0.8
0.8
0.8
0.8
0.635
0.635
0.635
0.635
1200 Vdc / 480Vac
104M48QH39
0.1
39
2
1.60
0.64
1.04
1.29
0.032
0.032
40.6
16.3
26.4
32.7
0.8
0.8
1600 Vdc / 660Vac
104M66QV39
0.1
39
2
2.18
0.54
1
1.8
0.032
0.032
55.3
13.7
25.4
45.7
0.8
0.8
UL/CSA Recognized Across-the-Line Application
104MACQRL150
104MACQRL680
0.1
0.1
150
680
1/2
1/2
1.08
1.08
0.44
0.44
Type QRL 125VAC
0.66
0.66
0.82
0.82
0.032
0.032
Type QRL complies with UL1414/CSA-C22.2 No. 1
0.025
0.025
27.4
27.4
11.18
11.18
16.7
16.7
20.8
20.8
0.8
0.8
0.635
0.635
Type QRL: UL File No. E33628, CSA File No. LR32208
1
Two watt resistor is wire wound
Shaded items are stocked parts
