BCM5751M
®
10/100/1000BASE-T CONTROLLER WITH INTEGRATED TRANSCEIVER
FEATURES
•
Single-chip device for desktop LAN-on-Motherboard (LoM) or
•
network interface card (NIC) applications
Integrated 10/100/1000BASE-T transceiver
•
10/100/1000BASE-T triple-speed MAC
•
High-speed RISC core with 24-KB cache
•
SMBus 2.0 controller
•
On-chip voltage regulation
•
Wake-on-LAN power switching circuit
PCI Express host interface
•
1x lane
•
4-pin interface
•
Functionality identical to PCI
Performance features
•
TCP, IP, and UDP checksum
•
Microsoft
®
Large Send Offload
•
Large burst read
•
Interrupt coalescing
Robust Wake on LAN (WOL)
•
Standards-compliant WOL
•
Innovative out-of-box mode WOL
•
Hardware power switching
•
Comprehensive diagnostic and configuration software suite
Industry-compliant alerting features
•
Alert Standard Format (ASF) 2.0 support
•
Secure power-on and power-off
•
Fast hardware authentication (SHA-1, HMAC, MD5)
•
True hardware random number generation
Integrated TPM functionality
•
Secure key management
•
Strong authentication capabilities
•
Platform state verification
3.3V I/Os (5V tolerant)
SUMMARY OF BENEFITS
•
Wirespeed performance increases user performance
•
PCI Express provides wirespeed non-blocking throughput
•
TCP and IP offloads significantly reduce utilization of CPU
•
TCP and IP offloads significantly increase throughput to
enable faster downloads of large files
Ultra-low power and Intelligent power management to
dramatically extend battery life
•
0.13µ CMOS design allows industry’s lowest power
•
Advanced situation-sensitive power management features
•
Power is continually reduced to the minimum needed
•
Adapts to usage model
Industry's smallest GbE form factor enables easier mobile
motherboard design
•
Innovative design reduces footprint to 67% smaller than
competing solutions
•
15-mm x 15-mm package
•
Integrated WOL switching eliminates external power
switching components
Proven TPM-based security features protect corporate
information
•
Protect valuable data against theft
•
Strong authentication to prevent unauthorized network access
•
Virus protection for VPN users exposed to Internet
Secure alerting and power cycling reduces IT costs
•
ASF 2.0 support for standards-based alerting. IT managers
receive automatic alerts when PC support issues occur.
•
Remote power-on/off features allow IT managers to power
cycle PCs to address issues.
•
Hardware-based authentication and random number generation
ensure the highest level of security possible.
Design flexibility allows feature consistency across SKUs
•
Layout compatible with PCI-based BCM5750M, enabling one
motherboard layout to support both PCI and PCI Express
•
Single software driver image across PCI and PCI Express
platforms
•
•
•
•
•
•
•
•
•
•
•
•
JTAG
OVERVIEW
RX
10/100/1000
PHY
TX
10/100/1000
MAC
Buffer
Memory
Memory
Controller
Processor
PCI
Express
25 MHz
PLL
Memory
PCI Express
Bus
LED Control
SMBus
EEPROM
Control
PLL
PCI
Clk
LED Signals
SMB Interface EEPROM Interface
diagnose any issues with the network cabling that could affect the host
machine. A link quality indicator LED and a GUI application give
installers an instant visual indication of problems. This includes physical
wiring defects or channel conditions, such as excessive cable length,
return loss, crosstalk, echo, and noise.
Broadcom's remote cable management and diagnostics software can be
used with the device to provide remote management of the cable and a
first level of diagnostics and fault isolation.
Target applications of the BCM5751M:
• Mobile PC NIC
• Mobile PC LOM
Software drivers available:
• Windows
®
98, NT, 2000, XP
• Linux
®
2.2, 2.4
The BCM5751M is a fully integrated 10/100/1000BASE-T Gigabit
Ethernet media access control and physical layer transceiver solution for
high-performance network applications. The BCM5751M combines a
triple-speed, IEEE 802.3 compliant media access controller (MAC), PCI
Express bus interface, on-chip buffer memory, and integrated physical
layer transceiver in a single device. It is fabricated in a low-voltage
silicon process, providing an ultra-low power solution. By itself the
BCM5751M provides a complete single-chip Gigabit Ethernet NIC or
LOM solution.
The BCM5751M includes a 10/100/1000-Mbps Ethernet MAC with full/
half-duplex capability at all speeds. Support for the following 802.3
functions is featured in the MAC: VLAN tagging, layer 2 priority
encoding, and full-duplex flow control.
The transceiver is fully compatible with the IEEE 802.3 standard for
auto-negotiation of speed. Additionally, several plug-and-play
enhancements are included to make the device even more user-friendly.
A unique integrated cable analyzer feature allows an end user to self-
Broadcom
®
, the pulse logo, and
Connecting everything
®
are trademarks of Broadcom Corporation and/
or its subsidiaries in the United States and certain other countries. All other trademarks mentioned are the
property of their respective owners.
®
BROADCOM CORPORATION
16215 Alton Parkway, P.O. Box 57013
Irvine, California 92619-7013
© 2004 by BROADCOM CORPORATION. All rights reserved.
5751M-PB02-R
01/03/05
Phone: 949-450-8700
Fax: 949-450-8710
E-mail: info@broadcom.com
Web: www.broadcom.com
