05165
ET720
Only One Name Means ProT
ek’Tion™
STEERING DIODE ARRA
Y
APPLICA
TIONS
✔
Ethernet - 10/100/1000 Base T
✔
Cellular Phones
✔
Handheld Electronics
✔
FireWire
✔
USB Interface
IEC COMPA
TIBILITY
(EN61000-4)
✔
61000-4-2 (ESD): Air - 15kV, Contact - 8kV
✔
61000-4-4 (EFT): 40A - 5/50ns
✔
61000-4-5 (Surge): 12A, 8/20µs - Level 1(Line-Gnd) & Level 2(Line-Line)
FEA
TURES
✔
ESD Protection > 40 kilovolts
✔
Provides 14 Lines of Protection
✔
LOW LEAKAGE CURRENT < 20nA
✔
ULTRA LOW CAPACITANCE: 3pF Typical
MECHANICAL CHARACTERISTICS
✔
Molded JEDEC SO-16
✔
Weight 0.15 grams (Approximate)
✔
Flammability rating UL 94V-0
✔
16mm Tape and Reel Per EIA Standard 481
✔
Marking: Part Number, Logo, Date Code & Pin One Defined By Dot on Top of Package
SO-16
PIN CONFIGURA
TION
V
CC
V
IO
V
I/O
V
I/O
V
I/O
V
I/O
V
I/O
V
I/O
16
15
14
13
12
11
10
9
1
V
I/O
2
V
I/O
3
V
I/O
4
V
I/O
5
V
I/O
6
V
I/O
7
V
I/O
8
GND
05165.R3 8/03
1
www.protekdevices.com
ET720
DEVICE CHARACTERISTICS
MAXIMUM RATINGS @ 25°C Unless Otherwise Specified
PARAMETER
Operating Temperature
Storage Temperature
Continuous Power Dissipation
SYMBOL
T
J
T
STG
P
PC
VALUE
-55°C to 150°C
-55°C to 150°C
145
UNITS
°C
°C
mW
ELECTRICAL CHARACTERISTICS PER LINE @ 25°C Unless Otherwise Specified
PART
NUMBER
DEVICE
MARKING
REPETITIVE
PEAK
REVERSE
VOLTAGE
(See Note 1)
V
RRM
VOLTS
ET720
ET720
30
TYPICAL
FORWARD
VOLTAGE
8/20µs
@1A
V
F
VOLTS
2
MAXIMUM
PEAK PULSE
FORWARD
CURRENT
8/20µs
I
FM
AMPS
12
MAXIMUM
REVERSE
LEAKAGE
CURRENT
V
RRM
@20V
I
R
nA
20
MAXIMUM
QUIESCENT
SUPPLY
CURRENT
@20V
I
RQ
nA
200
TYPICAL
CAPACITANCE
(See Note 2)
@0V, 1 MHz
Cj
pF
3
Note 1:
V
RRM
is +V
CC
for pin 16, -V
EE
for pin 1.
Note 2:
Measure C
j
between any V
I/O
pins to ground and divide by 2.
FIGURE 1
NON-REPETITIVE PEAK PULSE CURRENT CAPABILITY
8
I
PP
- Peak Pulse Current - % of I
PP
Peak Pulse Current - Amps
120
100
80
60
40
20
0
t
f
FIGURE 2
PULSE WAVE FORM
Peak Value I
PP
TEST
WAVEFORM
PARAMETERS
t
f
= 8µs
t
d
= 20µs
6
e
-t
4
2
t
d
= t I /2
PP
0
0.001
0.01
0.1
1
Square Wave Pulse - ms
10
100
0
5
10
15
t - Time - µs
20
25
30
05165.R3 8/03
2
www.protekdevices.com
ET720
PACKAGE OUTLINE & DIMENSIONS
PACKAGE OUTLINE
-A-
SO-16
16
9
-B- P
1
8
0.010” (0.25 MM)
M
B
M
8 PL
PACKAGE DIMENSIONS
DIM
MILLIMETERS
MIN
MAX
9.80
3.80
1.35
0.35
0.40
1.27 BSC
0.19
0.10
5.80
0.25
INCHES
MIN
MAX
G
C
0º - 7º
-T-
K
16 PL
0.010” (0.25 MM)
M
T B
S
M
R X 45º
D
A
S
F
J
A
B
C
D
F
G
J
K
P
R
NOTES
0.393
10.00
0.386
4.00
0.150
0.157
0.068
1.75
0.054
0.014
0.019
0.49
1.25
0.016
0.049
1.27 BSC 0.05 BSC 0.05 BSC
0.25
0.008
0.009
0.009
0.25
0.004
0.229
0.244
6.20
0.50
0.010
0.019
MOUNTING PAD
0.050” TYP
0.030”
±
0.005”
1. - T - = Seating Plane and Datum Surface.
2. Dimensions “A” and “B” are Datum.
3. Dimensions “A” and “B” do not include mold
protrusions.
4. Maximum mold protrusion is 0.015” (0.380 mm)
per side.
5. Dimensioning and tolerances per ANSI Y14.5M,
1982.
6. Dimensions are exclusive of mold flash and metal
burrs.
TAPE & REEL/BULK ORDERING NOMENCLATURE
0.160”
±
0.005”
0.245” MIN
1. Surface mount product is taped and reeled in accordance
with EIA-481.
2. Suffix-T7 = 7 Inch Reel - 1,000 pieces per 16mm tape,
i.e.,
ET720-T7.
3. Suffix-T13 = 13 Inch Reel - 2,500 pieces per 16mm tape,
i.e.,
ET720-T13.
4. No Suffix = Product Shipped in Tubes of 37 pcs per Tube.
0.045”
±
0.005”
Outline & Dimensions: Rev 1 - 11/01, 06007
COPYRIGHT © ProTek Devices 2003
SPECIFICATIONS: ProTek reserves the right to change the electrical and or mechanical
characteristics described herein without notice (except JEDEC).
DESIGN CHANGES: ProTek reserves the right to discontinue product lines without notice, and that
the final judgement concerning selection and specifications is the buyer’s and that in furnishing
engineering and technical assistance, ProTek assumes no responsibility with respect to the
selection or specifications of such products.
ProTek Devices
2929 South Fair Lane, Tempe, AZ 85282
Tel: 602-431-8101 Fax: 602-431-2288
