MKP1847 AC Filtering
www.vishay.com
Vishay Roederstein
Metallized Polypropylene Film Capacitor
AC Filtering Radial Type
FEATURES
• High peak current capabilities
• Long lifetime
• Material categorization:
for definitions of compliance please see
www.vishay.com/doc?99912
APPLICATIONS
•
•
•
•
•
AC filtering
UPS systems
Renewable energy - grid interface
Harmonic filter
Welding equipment
QUICK REFERENCE DATA
Rated capacitance range
Capacitance tolerance
Maximum continuous AC voltage (50 Hz / 60 Hz) range, U
NAC
Climatic testing class
Maximum application temperature
Maximum permissible case temperature
Reference standards
Dielectric
Electrodes
Construction
Encapsulation
Terminals
Self inductance (L
S
)
Withstanding DC voltage between terminals
Insulation resistance
Life time expectancy
(2)
Marking
(1)
1 μF to 70 μF
± 5 % and 10 %
230 V
AC
, 250 V
AC
, 275 V
AC
, 310 V
AC
, 350 V
AC
, 440 V
AC
40/85/56
105 °C
105 °C
IEC 61071, IEC 60068
Polypropylene film
Metallized dielectric film
Mono and internal serial construction
Plastic case sealed with resin; flame retardant
Tinned wire
< 1 nH per mm of lead spacing
1.5 U
NDC
for 10 s, cut off current 10 mA, rise time
1000 V/s
RC between leads, after 1 min > 10 000 s
Measuring voltage: 500 V
Useful lifetime: > 60 000 h at U
NAC
FIT: < 10 x 10
-9
/h (10 per 10
9
component hours) at 0.5 x U
NAC
, 40 °C
C-value; tolerance; rated voltage; code for dielectric material;
code for manufacturing origin; manufacturer’s type designation;
manufacturer location, year and week; manufacturer’s logo or name
Notes
• For more detailed data and test requirements, contact
dc-film@vishay.com
• For general information like characteristics and definitions used for film capacitors follow the link:
www.vishay.com/doc?28147
(1)
See document “Voltage Proof Test for Metalized Capacitors” (www.vishay.com/doc?28169)
(2)
Statements about life time are based on calculations which are based on internal tests. They have to be understood exclusively as
estimations. Also due to external factors, the life time in the field application may deviate from the calculated life time
AC VOLTAGE RATINGS (V
RMS
)
U
NAC
U
OPAC
at 85 °C
U
OPAC
at 105 °C
230 V
230 V
160 V
250 V
250 V
175 V
275 V
275 V
190 V
310 V
310 V
210 V
350 V
350 V
240 V
440 V
440 V
300 V
