LESHAN RADIO COMPANY, LTD.
BR605 – BR610
KBPC6005 – KBPC0610
6.0A
6.0A BRIDGE RECTIFIERS
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified. Single phase,half wave,
60Hz,resistive or inductive load. For capacitive load,derate current by 20%.
Maximum
TYPE
Peak
Reverse
Voltage
PRV
V
PK
Maximum
Maximum
Average Forward Peak
Forward
Surge Current
Output
@ 8.3ms
Current
@T
A
= 50°C Superimposed
I
O
Maximum DC
Forward Voltage
drop per element
at I
F
=3.0ADC
V
F
V
PK
Maximum DC
Reverse Current
at rated DC
Blocking Voltage
per element
I
R
25°CTA
µADC
125°CTA
µADC
Operating
Junction
Temperature
Package
Dimensions
I
FM
(Surge)
A
PK
T
J
°C
A
AV
BR605
BR61
BR62
BR64
BR66
BR68
BR610
KBPC6005
KBPC601
KBPC602
KBPC604
KBPC606
KBPC608
KBPC0610
50
100
200
400
600
800
1000
6.0
150
1.1
10
500
125
BR – 6
.270(6.8)
.230(5.8)
.042(1.1) DIA
.039(1.0)
TYP.
.750 MIN
(19.1)
.620(15.7)
.580(14.7)
.445(11.3)
.405(10.3)
HOLE FOR
NO.6 SCREW
.620(15.7)
.580(14.7)
.444(11.3)
.405(10.3)
BR – 6
12C–1/2
LESHAN RADIO COMPANY, LTD.
BR605 –BR610 KBPC6005 – KBPC0610
BRIDGE RECTIFIERS RATING AND CHARACTERISTIC CURVES
FIG. 1 - TYPICAL FORWARD CURRENT
DERATING CURVE
8
AVERAGE FORWARD OUTPUT CURRENT AMPERES
FIG. 2 - MAXIMUM NON-REPETITIVE
SURGE CURRENT
150
PEAK FORWARD SURGE CURRENT.AMPERES
6
120
90
4
60
2
30
0
1
2
5
10
20
50
100
0
0
50
100
150
NUMBER OF CYCLES AT 60Hz
AMBIENT TEMPERATURE.°C
FIG. 3 - TYPICAL REVERSE CHARACTERISTICS
FIG. 4 - TYPICAL INSTANTANEOUS FORWARD
PER BRIDGE ELEMENT
100
INSTANTANEOUS FORWARD CURRENT AMPERES
INSTANTANEOUS REVERSE CURRENT MICROAMPERES
100
T
C
= 100°C
10
10
1.0
1.0
T
A
= 25°C
0.1
T
J
= 25°C
Pulse Width=300µs
1% Duty Cycle
0.01
0.6
0.8
1.0
1.2
1.4
1.6
1.8
2.0
.1
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE,(%)
FORWARD VOLTAGE (V)
12C–2/2
