DC COMPONENTS CO., LTD.
R
KBPC
50005
MB
5005
RECTIFIER SPECIALISTS
THRU
KBPC
MB
5010
5010
TECHNICAL SPECIFICATIONS OF SINGLE-PHASE SILICON BRIDGE RECTIFIER
VOLTAGE RANGE - 50 to 1000 Volts
CURRENT - 50 Amperes
FEATURES
* Metal case for Maximum Heat Dissipation
* Surge overload ratings-400 Amperes
* Low forward voltage drop
MB-25
TY
MECHANICAL DATA
* Case: Metal, electrically isolated
* Epoxy: UL 94V-0 rate flame retardant
* Terminals: Plated .25"(6.35mm) Faston lugs, solderable per
MIL-STD-202E, Method 208 guaranteed
* Polarity: As marked
* Mounting position: Any
* Weight: 30 grams
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Dimensions in inches and (millimeters)
o
KBPC
50005
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Bridge Input Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Output Current at Tc = 55 C
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC Method)
Maximum Forward Voltage Drop per element at 25A DC
Maximum DC Reverse Current at Rated
DC Blocking Voltage per element
I
2
t Rating for Fusing (t<8.3ms)
Typical Junction Capacitance ( Note1)
Typical Thermal Resistance (Note 2)
Operating and Storage Temperature Range
NOTES : 1.Measured at 1 MH
Z
and applied reverse voltage of 4.0 volts
2. Thermal Resistance from Junction to Case per leg.
@T
A
= 25 C
@T
A
= 100 C
I
2
t
C
J
RθJ C
T
J,
T
STG
o
o
o
KBPC
5001
MB501
100
70
100
KBPC
5002
MB502
200
140
200
KBPC
5004
MB504
400
280
400
50
400
1.1
10
500
664
300
2.0
-55 to + 150
KBPC
5006
MB506
600
420
600
KBPC
5008
MB508
800
560
800
KBPC
5010
MB5010 UNITS
1000
700
1000
Volts
Volts
Volts
Amps
Amps
Volts
uAmps
A
2
Sec
pF
0
SYMBOL
V
RRM
V
RMS
V
DC
I
O
I
FSM
V
F
I
R
MB5005
50
35
50
C/W
C
0
272
